Control panel
1-2 Digital readouts, AMOUNT OF UNBALANCE, inside/outside
Buttons to read unbalance below threshold
3-4
Digital readouts, POSITION OF UNBALANCE, inside/outside
5
Push button, selection of mode of correction
6
Push button, unbalance reading < 5 g (25 oz)
7
Push button, FUNCTIONS MENU
8
Push button, menu selection confirmation
9
Push button, cycle start
10
Push button, emergency/home
11
Position repeater push button
12
Push button, SPLIT
(unbalance spread)
13
Manual width setting buttons
cAuTIoN
p
Ress
The
buTToNs
WITh
youR
fINGeRs
. N
eveR
use
The
couNTeRWeIGhT
GRIppeRs
oR
oTheR
poINTed
objecTs
!
W
heN
The
beep
sIGNAl
Is
eNAbled
pRessING
of
ANy
push
buTToN
Is
AccompANIed
by
A
“
beep
”.
