PC 8172 User’s Manual

72

Power Supply Specification


SHORT CIRCUIT PROTECTION

Output short circuit is defined to be a short circuit load of less than 0.1
ohm.

In the event of an output short circuit condition on +3.3V, +5V or +12V
output, the power supply will shutdown and latch off. The power supply
shall return to normal operation after the short circuit has been
removed and the power switch has been turned off for no more than 2
seconds.

OVERLOAD PROTECTION

Overload currents defined as a 10 amp/sec fault current ramp starting
from full load, applied to the +3.3V, +5V output, shall not cause that
output to exceed 32 amps before the output voltage drops below 0.5
volts and is latched off. The +12V output shall not exceed 20 amps under
the same ramp conditions starting at full load before it is latched off.

POWER SIGNAL

100 –500mSec.

POWER GOOD @ 115/230V,FULL LOAD

POWER FAIL @115/230V, FULL LOAD

1 mSec. minimum

2.

Efficiency

Typical

load

Loading

Voltage

Full load

Light load

Required Minimum

115V

80%

81%

80%

Efficiency

Required Minimum

230V

81%

82%

80%

Efficiency


3.

Environmental Requirements

f

Operating temperature range: 10

°C to 50°C

f

Storage temperature range: -20

°C to +80°C

f

Humidity, non-condensing: 5% ~ 95%RH, Non-

Condensing
