Page 13
Introduction
3
PC 8172 User’s Manual
1.2 System Specifications
1.2.1 Main CPU Board
a
CPU
®
f
Socket LGA775 for Intel
Core
TM
2 Duo/Core
TM
Solo
Processor with FSB 533/800/1066 MHz , max up to
E6400.
NOTE It doesn’t support the processor with FSB 1333 MHz,
and it is not recommended to use Quad-Core CPU.
a
System Chipset
®
f
Intel
a
BIOS
Q965 + ICH8
f
Phoenix-Award BIOS, 16Mbit with RPL/PXE LAN Boot ROM,
SmartView and Customer CMOS Backup
a
System Memory
f
Two 240-pin DDR2 DIMM maximum up to 4GB
a
L2 Cache
f
Integrated in CPU
a
Bus Clock
f
533/800/1066 MHz
a
Watchdog Timer
f
Up to 255 levels as Reset feature
1.2.2
I/O System
a
Standard I/O
f
Three serial ports with power, two RS-232 and one RS-
232/422/485
f
One PS/2 for Keyboard and Mouse Interface
f
Four USB Ports 2.0 compliant
f
Two IEEE1394a Ports
