Phoenix-Award BIOS Utility

PC817 User’

s Manual

Master/Slave PIO items on the menu.

IDE Master/Slave PIO

The four IDE PIO (Programmed Input/Output) fields let you
set a PIO mode (0-4) for each of the four IDE devices that
the onboard IDE interface supports. Modes 0 to 4 provide
successively increased performance. In Auto mode, the
system automatically determines the best mode for each
device.

IDE Master/Slave UDMA

Select the mode of operation for the IDE drive. Ultra DMA-
33/66/100/133 implementation is possible only if your IDE
hard drive supports it and the operating environment
includes a DMA driver. If your hard drive and your system
software both support Ultra DMA-33/66/100/133, select Auto
to enable UDMA mode by BIOS.

SATA Mode

There are these options for you to set up SATA mode: IDE,
RAID or AHCI.

NOTE ICH8DO supports AHCI under Microsoft

Windows VISTA and Microsoft Windows XP.
ICH8 only supports AHCI under Microsoft
Windows VISTA.

LEGACY Mode Support

Legacy mode support allows devices to function in an
operating environment that is not USB-aware.

Press to return to the Integrated Peripherals page.
