10 Appendix E – Control Box Works
21.93
Note:
SN: 61076 and above
Castle Inc
TSM-21 Diagnostic Manual v2
Page 60 of 63
Fig 33
Fig 34
Regulator Knob
Router Feed Rate Knob
Router Solenoid
Drill Solenoid
Clamp Solenoid
Air OUT lines
Air IN lines
View from front of
machine with work top
removed
Air IN Lines
Exhaust Ports
