Castle Inc TSM-21 Diagnostic Manual v2 Page 12 of 63
4.2 Router Operation
Page Procedure
Router doesn’t cut pocket…Machine Clamps and Drills, but Clamp DOES NOT release:
□ Check Router Feed Rate may be turned all the way down……... 31-32 21.32
□ Check Router Solenoid for function or blockage…………………. 30-31 21.31
□ Unclog Router Solenoid…………………………………………….. 29-30 21.30
□ Router Motor Operation…………………………………………….. 24-26 21.20
□ Check Router SQE Valve …………………………………………..
(or Solenoid exhaust port ) for leakage 43-44 21.61
□ Check Drill SQE Valve……………………………………………….
(or Solenoid exhaust port ) for leakage 43-44 21.61
Router doesn’t cut pocket… Machine Clamps, Drills and releases:
□ Check Router Stop Switch for function or adjustment…………… 27-29 21.22
Router comes up and STAYS UP as soon as air is attached…..with Machine power OFF:
□ Check Router Solenoid for function or blockage…………………. 30-31 21.31
□ Unclog Router Solenoid…………………………………………….. 29-30 21.30
Router cuts pocket and STAYS UP, Drill doesn’t come out and Clamp doesn’t release:
□ Check Router Stop Switch for function or adjustment…………… 27-29 21.22
Router cuts pocket, Drill doesn’t come out and Clamp doesn’t release:
□ Check Drill Solenoid for function or blockage…………………….. 38-39 21.50
Router advances too aggressively:
□ Adjust internal Air Pressure………………………………………… 51-52 21.90
□ Adjust the Router Feed Rate……………………………………….. 31-32 21.32
