Castle Inc TSM-21 Diagnostic Manual v2 Page 14 of 63
Page Procedure
Drill bit breaking:
□ Adjust air pressure, Machine cycling too fast …………………….. 51-52 21.90
□ Bit extended too far out of collet…………………………………… 34-35 21.41
□ Check Drill T-Handle bolt…………………………………………… 33-34 21.40
4.4 Overall Machine Operation and Pocket Adjustment
Page Procedure
Machine will not start cycle…motors are running:
□ Check Air Supply, minimum 85 PSI required…………………….. 54 21.92
□ Check Safety Switch………………………………………………… 47-48 21.82
□ Check Foot Switch…………………………………………………... 45-46 21.80
Machine can be cycled with no stock in place:
□ Check the Safety Switch……………………………………………. 47-48 21.82
Machine cycling too slowly
Note: A normal cycle is approximately 2 seconds
□ Adjust Air Pressure Regulator……………………………………… 51-52 21.90
□ Check Drive cylinder for air leak…………………………………… 41-42 21.60
□ Check for other air driven machines on the same line…………... 51-52 21.90
