48 appendices – MoTeC PDM30 User Manual
Page 51
48
Appendices
CAN Address Byte Bit
Channel
Scaling
Base address
+ 2
0
0..7
Compound Id = 0
1
0..7
Output 1 Load
0 to 255 = 0 to 255%
1% steps
2
0..7
Output 2 Load
3
0..7
Output 3 Load
4
0..7
Output 4 Load
5
0..7
Output 5 Load
6
0..7
Output 6 Load
7
0..7
Output 7 Load
Base address
+ 2
0
0..7
Compound Id = 1
1
0..7
Output 8 Load
0 to 255 = 0 to 255%
1% steps
2
0..7
Output 9 Load
3
0..7
Output 10 Load
4
0..7
Output 11 Load
5
0..7
Output 12 Load
6
0..7
Output 13 Load
7
0..7
Output 14 Load
Base address
+ 2
0
0..7
Compound Id = 2
1
0..7
Output 15 Load
0 to 255 = 0 to 255%
1% steps
2
0..7
Output 16 Load
3
0..7
Output 17 Load
4
0..7
Output 18 Load
5
0..7
Output 19 Load
6
0..7
Output 20 Load
7
0..7
Output 21 Load
Base address
+ 2
0
0..7
Compound Id = 3
1
0..7
Output 22 Load
0 to 255 = 0 to 255%
1% steps
2
0..7
Output 23 Load
3
0..7
Output 24 Load
4
0..7
Output 25 Load
5
0..7
Output 26 Load
6
0..7
Output 27 Load
7
0..7
Output 28 Load
Base address
+ 2
0
0..7
Compound Id = 4
1
0..7
Output 29 Load
0 to 255 = 0 to 255%
1% steps
2
0..7
Output 30 Load
3
0..7
Output 31 Load
4
0..7
Output 32 Load
