30 Appendices
Appendices
Specifications
General
Battery voltage 30 V max, 6.5 V min
Current consumption 35 mA typical operating
5 mA typical standby
Total output current
(continuous) PDM16 PDM32 PDM15 PDM30
100 A 120 A 80 A 100 A
Reverse battery
protection Protection for PDM and all connected devices
Load dump transient
protection Protection for PDM.
Also assists in protecting connected devices.
Operating temperature 110 °C max internal (100 °C recommended)
Typical 85 °C max ambient for 120 A total load (for
110 °C internal) depending on mounting, air
circulation and load distribution.
These specifications apply for a 12 V battery.
For a 24 V battery reduce specified temperatures
by 20 °C.
Weight PDM16 PDM32 PDM15 PDM30
330 g
(0.72 lbs) 405 g
(0.89 lbs) 260 g
(0.57 lbs) 270 g
(0.59 lbs)
Length 130 mm
(5.1") 180 mm
(7.1") 107 mm
(4.2") 107 mm
(4.2")
Width 60 mm
(2.4") 60 mm
(2.4") 133 mm
(5.2") 133 mm
(5.2")
Height 28 mm
(1.1") 28 mm
(1.1") 39 mm
(1.5") 39 mm
(1.5")
Case Machined aluminium Magnesium
Environmental
protection Rubber seal on lid and
connectors, conformal
coating on PCB Conformal coating on
PCB
