36 Appendices
PDM32
Connector A
Connector B
37 pin Autosport 26 pin Autosport
Mating connector #68089 Mating connector #65040
Pin Function Pin Function
A_1 Digital/Switch Input 1 B_A 8 A Output 9
A_2 Digital/Switch Input 2 B_B 8 A Output 10
A_3 Digital/Switch Input 3 B_C 8 A Output 11
A_4 Digital/Switch Input 4 B_D 8 A Output 12
A_5 Digital/Switch Input 5 B_E 8 A Output 13
A_6 0 V B_F 8 A Output 14
A_7 0 V B_G 8 A Output 15
A_8 0 V B_H 8 A Output 16
A_9 0 V B_J 8 A Output 17
A_10 CAN Low B_K 8 A Output 18
A_11 CAN High B_L 8 A Output 19
A_12 Digital/Switch Input 6 B_M 8 A Output 20
A_13 Digital/Switch Input 7 B_N 8 A Output 21
A_14 Digital/Switch Input 8 B_P 8 A Output 22
A_15 Digital/Switch Input 9 B_R 8 A Output 23
A_16 Digital/Switch Input 10 B_S 8 A Output 24
A_17 Digital/Switch Input 11 B_T 8 A Output 25
A_18 Digital/Switch Input 12 B_U 8 A Output 26
A_19 Digital/Switch Input 13 B_V 8 A Output 27
A_20 Digital/Switch Input 14 B_W 8 A Output 28
A_21 Digital/Switch Input 15 B_X 8 A Output 29
A_22 0 V B_Y 8 A Output 30
A_23 0 V B_Z 8 A Output 31
A_24 0 V B_a 8 A Output 32
A_25 0 V B_b Batt
–
A_26 Digital/Switch Input 16 B_c Batt
–
A_27 Digital/Switch Input 17
A_28 Digital/Switch Input 18
A_29 Digital/Switch Input 19
A_30 Digital/Switch Input 20
A_31 Digital/Switch Input 21
A_32 Digital/Switch Input 22
A_33 Digital/Switch Input 23
A_34 Not Connected
A_35 Not Connected
A_36 Not Connected
A_37 Not Connected
