MoTeC
Appendices
43
Wiring
Wire Specification
M22759/16
Insulation Material: Tefzel
Conductor: Tin Plated Copper
Voltage Rating: 600 V
Maximum Temperature: 150
C
Wire
Gauge
(AWG)
Current Rating
at 80 °C ambient
[A]*
Current Rating
at 100 °C ambient
[A]*
Resistance
[ohm/m]
Resistance
[ohm/1000 ft]
24#
4.5
4
0.071
22
22#
6
5
0.045
14
20#
8
6
0.028
8.5
18#
11
9
0.018
5.5
16#
15
12
0.014
4.3
14#
22
18
0.009
2.7
6#
90‡
75‡
0.0015
0.44
4#
120‡
100‡
0.0009
0.28
2#
150‡
120‡
0.0006
0.18
*The current ratings above are an indication only and will not apply in all
circumstances.
The actual maximum current rating is determined by the maximum allowed
temperature for the wire (150 °C).
The temperature of the wire is affected by many factors including the
temperature of adjacent wires, how the wires are bundled and covered, the
ambient temperature and the current.
‡current rating for a single wire in free air
Recommended Wire Gauge
Output
24# to 20#
8 Amp outputs
20# to 16#
20 Amp outputs
4# to 2#
Battery pos
