Step 9 Re-connect output and AC wires to the new supply using wire nuts or
another suitable connection.
Step 10 Apply power to ensure the beacon lights up correctly.
Section 6: Specifications
Power Supply Specifications (D564-9000)
Input Voltage Range
120-240VAC at 50/60Hz
Nominal Input Power 19W (steady burn)
Power Factor >0.9
ATHD <20%
Beacon Specifications
Light Color
Red
Weight 18 Pounds
Height 8.4 Inches
Width 15.0 Inches
Bolt Hold down Pattern Standard Pattern provided (See Fig. 2)
Section 7: Regulatory Compliance and Certifications
7.1 ETL Certified to: Federal Aviation Administration (FAA): AC No. (150/5345-
43). Refer to website for latest certifications.
Section 8: How to Obtain Warranty Service
Refer to www.dialight.com
