Chenbro ES34169 - Installation User Manual
Page 8
www.chenbro.com
8
ES34169 Chassis User’s Manual Rev. A1
Motherboard Cage Removal
1
2
3
4
5
■ Release 6 secure screws on the M/B cage
■ Remove the motherboard cage
■ Disconnect the extension fan cables
■ Detach the motherboard cage with System Cables
(SATA, Power, Fan cables) through the cable routing hole
■ Finish detaching the M/B cage and make sure all the
connection on backplane and PDB are still tight before
assembly back the M/B cage
