ES34169 Chassis User’s Manual Rev. A1
Features
z
120 watts internal power supply
z
Ideal for high storage capacity (Hot-swap HDDs) with RAID-5 functionality
z
Available for multi-media platform
z
9.5 liters small form factor with Mini-ITX M/B
z
Removable M/B carrier for excellent thermal performance & easy cabling
z
External adapter reduces noise level
z
Optional remote control & riser card
Technical Specifications
Model Name
◆ES34169
M/B Form Factor
◆Mini-ITX
Dimension (DxWxH)
◆260mm x140mm x260mm ◆10.24" x 5.51" x 10.24"
Drive Bay
◆Hot-swap: 3.5" x4 ◆Internal: 2.5" x1 (optional)
◆Slim ODD: 1 (optional)
PSU
◆Form Factor: External Adapter 120 W
Indicator LEDs
◆Power, HDD Activity, LAN x2, Fault
Front Control
◆Power, Reset & Alarm Mute Switches
Front Access
◆USB 2.0 x2 ◆SD/Mini-SD/MMC/MS Card Reader (optional)
Security
◆Kensington Lock & Padlock Loop
Cooling Fan
◆Front: 60mm (optional) ◆Rear: 70x15mm x2
Slot Opening
◆Low Profile x1
Material
◆SECC
Plastic Material Type
◆ABS-HB
Sheet Metal Thickness
◆0.7 mm
Net Weight
◆4.9 Kgs
Gross Weight
◆5.9 Kgs
Backplane
◆SATA-II / SAS
20'
40'
40'H
Container Info.
◆Single Packing
672
1344
1512
