Connecting devices – Chenbro ES34169 - Installation User Manual
Page 13
www.chenbro.com
13
ES34169 Chassis User’s Manual Rev. A1
Installing 2.5” HDD
Connecting Devices
z
Four SATA-II cables for Hot-swap hard drive (HDD)
z
Power cables for M/B
z
Front panel I/O cables
z
USB 2.0 cable
Connecting SATA-II Cables
Note: If there is no enough SATA port on M/B, users can either remove or keep the
bundled P3/P4 SATA cable.
1
2
■ Check the bundled cable with number tag
■ Connect the SATA cables to the M/B properly
1
2
■ Place 2.5” HDD underneath the Slim ODD
■ Fix the 2.5” HDD with attached screws
Note: To install 2.5” HDD, disassemble the M/B cage is required.
