ES34169 Chassis User’s Manual Rev. A1
Power Supply
Specification:
Input Characteristics Output Characteristics
Item Spec Item Spec
Rated Input Voltage 115 V ~ 230 Vrms Output Voltage 3.3 V, 5 V, 12 V
Input Voltage Range 90 ~ 264 Vrms Efficiency 80 %
Input Frequency Range 47 Hz ~ 63 Hz
Protection:
z Over-Voltage Protection
z Short Circuit Protection
z No Load Operation
z Reset After Shutdown
z Input Over Current Protection
Environmental Requirements:
z Temperature: -10 ~ 50 ℃ @ Operating; -40 ~ 70 @ Non-operating
z Humidity: 5% ~ 90% @ Operating; 5% ~ 90% @ Non-operating
Mechanical Dimension :
50 mm * 35 mm * 183.7 mm
