Opening the chassis – Chenbro ES34169 - Installation User Manual
Page 6
www.chenbro.com
6
ES34169 Chassis User’s Manual Rev. A1
Opening the Chassis
Front
Overview
Slim CD-ROM Carrier
(Optional)
Motherboard cage
Main Cable through hole
w/ rubber pad
Front Bezel
(w/Key Lock)
USB & front
Control cables
Intrusion
switch
Card Reader (Optional)
USB 2.0 ports x2
Slim ODD Cover
Front Control Display:
Power Status LED (Blue)
HDD Access LED (Amber)
LAN#1 Activities LED (Green)
LAN#2 Activities LED (Green)
Global Failure LED (Red)
Front Control Switches:
Power On Switch
System Reset
Alarm Mute
4x 3.5” HDD Carrier
Side Panel w/Venting
Back
Pad Lock
Rear 70mm fans (x2)
Power connector
Side Panel Screw
Kensington lock
Low profile
Slot opening
LED VCC & recovery
switch (optional)
