Chenbro ES34169 - Installation User Manual
Page 10
www.chenbro.com
10
ES34169 Chassis User’s Manual Rev. A1
Installing 3.5” SATA-II Hard Drive
Installing Card Reader
1
2
3
4
1
2
■ Detach the front screw of Card Reader holder
■ Pull out the Card Reader holder
■ Remove the HDD Carrier from the chassis and place
the SATA-II HDD into it.
■ Attach the HDD screws on both sides
■ Slide in the assembled HDD into the chassis, suggest
install by the ID definition on the front panel
(No need to remove the front bezel)
■ Make sure the carrier is fully seated
