Camco D-Power 7 - Manual (Page 29)

D - P O W E R
S E R I E S
Vrms
-120
-20
-110
-100
-90
-80
-70
-60
-50
-40
-30
dB
100u 5 200u 500u 1m 2m 5m 10 m 20m 50m 100m 200m 500m 1 2
Hz
dB
20 10k 50 100 200 500 1k 2k 5k
-120
-20
-110
-100
-90
-80
-70
-60
-50
-40
-30
Hz
Ω
Hz
0
1000
200
400
600
800
damping factor
USER MANUAL
D-POWER 7
P.28
Figure 7.6
THD+N vs. input voltage @ 1 kHz, 4 Ω (Ch1, Ch2 )
(Measurements of a typical performance)
Figure 7.8
THD+N vs. frequency (BW 22 kHz), 10 dB below clip, 4 Ω (Ch1, Ch2 )
(Measurements of a typical performance)
Figure 7.5
Output impedance vs. frequency @ 1 Amp RMS injected current (Ch1,
Ch2 ) equivalent 11 mΩ + 2,1 uH (Measurements of a typical performance)
Figure 7.7
Damping factor into 8 Ω (Ch1, Ch2 )
equation: damping factor = loaded impedance / amplifier output imped-
ance (Measurements of a typical performance)
7 TYPICAL PERFORMANCE DIAGRAMS
