2.3 D-POWER 7 - The Front
1 Clip LEDs
7 Volume Control Channel A
2 Output Current LEDs
8 Volume Control Channel B
3 Signal LEDs
9 Removable Air Filter System
4 On LEDs
10 Cooling Air Inlet Vents
5 Parallel Mono Mode LED
11 On/Off Switch
6 Mono Bridge Mode LED
2.4 D-POWER 7 - The Rear
12 Rating Plate
18 Limiter Switch
13 SPEAKON
®
Connectors
19 Gain Selector
14 Cooling Air Outlet Vents
20 AC Power Connector
15 Input Ground Lift Switch
21 XLR - Line Inputs
16 Optional Feature Selector
22 XLR - Line Link Outputs
17 Mode Selector
