Camco D-Power 7 - Manual (Page 27)

D - P O W E R
S E R I E S
USER MANUAL
D-POWER 7
P.26
Frequency Range 20 Hz - 20 kHz ± 0,15 dB
8 Ω load, 10 dB below rated power
Input Impedance 40 kΩ balanced
Voltage Gain selectable: 26 dB, 32 dB, or 1,4 V input sensitivity
Protection Circuits inrush-current limitation, temperature monitoring of transformers and heatsinks,
output DC protection, SOA protection, output over current protection,
under impedance limiter, intelligent mains fuses protection
Limiter switchable clip- and speaker protect limiter
Fan two temperature dependent speed-controlled axial fans
Ground Lift input ground lift switch on back panel
Indicators LEDs for On, Signal, I-Out, Clip, Mode, indicating additionally Output Current and faults such as DC
and High Temperature
Input Connectors 3-pin XLR, male and female per channel, pin 2 = hot (inphase)
Output Connectors one 4-pole SPEAKON ® connector for each output channel (wired using 2 channel cable)
Modes of Operation Stereo, Mono Bridge and Parallel Mono
THD+N (typical) < 0,01 %
20 Hz - 10 kHz, 8 Ω load,
10 dB below rated power
SMPTE (typical) < 0,01 %
20 Hz - 20 kHz, 8 Ω load,
10 dB below rated power
Damping Factor > 400
8 Ω load, 1 kHz and below
Dimensions (WxHxD) 483 x 88,9 x 422 mm (19”, 2U)
Net Weight 12,4 kg
Shipping Dimensions (WxHxD) 615 x 135 x 540 mm (0,045 m3)
Shipping Weight 15 kg
We reserve the right to make technical alterations without prior notice
6 SPECIFICA
TIONS
