D - P O W E R
S E R I E S
xxxxxxx
D-POWER 7
230 V ~ 50/60 Hz 12 A 1800 W
3000 W / 2 Ohm
USER MANUAL
D-POWER 7
P.10
2.5 Factory settings
D-POWER 7
amplifiers are delivered with the following factory settings
Front panel:
On/Off Switch
Off
Amplifier is switched off
Rear panel:
Input Ground Lift
Grounded
Optional Feature
Circle
Mode
Stereo
Limiter
SpP
Gain
26
dB
3.1 Mains supply
When mounting or connecting the amp always disconnect it from
mains. Only connect the D-POWER 7 amplifier to an appropriate AC cir-
cuit and outlet, according to the requirements indicated in the second
line on the rating plate.
Exemplary rating plate for a mains supply of 230 V AC 50/60 Hz.
Power Supply Data:
Voltage
Mains Frequency Current
Power Consumption
100 V
50/60 Hz
28 A
1800 W
120 V
50/60 Hz
24 A
1800 W
220 V
60 Hz
12 A
1800 W
230 V
50/60 Hz
12 A
1800 W
NOTE: Even under normal conditions the mains current can reach lev-
els up to 60 A (230 V), 120 A (120 V) and 140 A (100 V), respectively;
this could cause lamps to flicker if connected to the same mains as
the amp. The impedance of the AC circuit should be less than 0,157
Ohms to avoid flicker according to EN61000-3-11 “Electromagnetic
compatibility – Part 3-11: Limits – Limitation of voltage changes, volt-
age fluctuations and flicker in the public low-voltage supply systems
– Equipment with rated current
≤ 75 A and subject to conditional connection”.
If in any doubt, consult your local power provider. Never attempt to
measure this impedance level with your ohmmeter. This may damage
your meter and expose you to the risk of electric shock!
