DIRECTIONS FOR USE
1) Extend the legs (1), as indicated in Fig. 1, and lock them in the adjusted height with the
supplied wing nut. Before tightening the wing nuts check that there is a washer
underneath.
2) Connect all three tripod legs to the tripod head with the wing nut and screw in the
manner as indicated in Fig. 2a).
b) For model 40070 / 40080 & 600X50 proceed as in figure 1A setting up the pre moun-
ted tripod and connecting it to the telescope with the micrometric screw that regulates
the movement of the telescope.
3) Now fasten the accessory tray (3) to the flanges of the tripod legs with the supplied
screws and wing nuts. (see Fig. 3)
4) After all screws have been firmly tightened, the telescope can be connected to the yoke
of the tripod head. Proceed as indicated in Fig. 2 for model 60050 / 70060 / 80060 /
70076
b) Mount the telescope main body (12) in the yoke, and adjust with the large locking screw.
Now adjust the pin of the micro adjustable altitude control with the guide provided for
this purpose (see Fig. 2 b + c).
c) Model 90060 / 900114 proceed as in Fig. 9.
5) Remove the finder scope (15) with attached bracket (14) from the box. Then remove
the two knurled thumb screws from the telescope main body (12). Position the finder
scope bracket on the telescope main body so that the holes in the base of the bracket
line up with the exposed holes in the telescope main body. Return the two knurled
thumb screws and tighten securely (see Fig. 4).
1 Tripod Leg
2 Tripod Leg Adjusting Screw
3 Accessory Tray
4 Polar Axis Locking Lever
5 Counterweight Shaft
6 Counterweight
7 Hour Axis Scale
8 Declination Scale
9 Objective Lens
10 Dust Caps
11 Cradle
12 Telescope Main Body
13 Eyepiece
14 Finderscope Bracket
15 Finderscope
16 Diagonal
17 Focus Tube
18 Focus Knob
19 Flexible Control Cable
20 Polar Axis Micro Adjustment Lever
