background image

INSTALLATION INSTRUCTIONS

Please read these instructions before

installing your scope mount.

The riflescope mount for your BARSKA riflescope is designed to be slightly

oversize in order to fit the a wide range of riflescopes. Depending on

manufacturing tolerances, it may be necessary to slightly modify it in order

for it to fit as tight as possible.

If the scope mount doesn't fit into your SKS receiver and the takedown lever

cannot be re-inserted throught the receiver,some minor filing will be required.

This filing should only be done on the scope mount. Modifications to your

SKS are not necessary using this procedure. This procedure should only take

a few minutes.

1. DETERMINE THE AMOUNT OF FILING NECESSARY

To determine how much filing is necessary, hold the scope mount firmly against

the receiver as far as it will go. Tap the scope mount with a rubber mallet (See

Fig. 1). The exact points on the two
angled "points" where the metal requires

removal will appear bright from being

tapped against the receiver.

2. FILING THE MOUNT

Carefully remove a very small amount

of metal from the mount using a small

hand file (See Fig 2). Be sure to

maintain the exact angle of the "points"

when removing metal. Attempt to install

the mount. If there is still inadequate

clearance, repeat this procedure until

there is just enough clearance to

"wedge" the mount into the receiver.

NOTE: Only a tiny amount of metal

needs to be removed for most SKS

rifles. Removing too much material will

result in a loose fit and too much "play".

Fig. 1

Fig. 2

If you have any questions, please call BARSKA Customer Service between

8:30 a.m. and 5:30 p.m. PST at (909) 445-8168.
