20-60x60 mm Zoom Scope

Model AA11128

PARTS

1 - Optical tube with arc mount attached

2 - Mahogany wood tripod

3 - Lock and levers

4 - Objective lens

5 - Eyepiece

6 - Focus knob

7 - Zoom ring

**IMPORTANT**

NEVER ATTEMPT TO CLEAN YOUR SCOPE INTERNALLY

OR TRY TO TAKE IT APART. DO NOT LOOK DIRECTLY

AT THE SUN WITH THE SCOPE AS IT WILL CAUSE

DAMAGE TO YOUR EYE

HOW TO ASSEMBLE YOUR SCOPE:

NOTE* Please be careful not to scratch your scope.

1. Place the optical tube and arc mount on its side.

2. Attach the legs of the tripod at the base of the mount.

3. Carefully slide one of the leg attachments shaft through the

top of the attached leg through the holes of the mount.

Hand fastens with washer and bolts.

4. Extend and lock the legs into position then gently stand

the scope and tripod, slowly spread the legs of the tripod.

Make sure to tighten all screws and nuts. Your scope is now

assembled and read to be used.

HOW TO USE YOUR SCOPE:

Start by loosening the lock and levers and gently guide the

scope to your desired position.

1. Once it’s at the position that you want, tighten the locks

and levers.

2. Point the objective lens to an object and look through

the eyepieces.

3. With slow and tiny motions, rotate the zoom ring, then

the focus knob slowly, until your view of the object is sharp

and in focus.

HOW TO TAKE CARE OF YOUR SCOPE:

1. When wiping the lenses, use a soft lens cloth.

2. To remove any remaining dirt or smudges, add one or two

drops of isopropyl alcohol to the cloth, then wipe gently.

3. Store your scope in a moisture-free area.

Parts included in package

Optical tube with mount attached

1 unit

Mahogany wood tripod legs

3 units

Washers and bolts

3 sets
