Carlon Expansion Fittings
ISEXPJT 0M 7/04 SP
© Lamson & Sessions 2004
Male Terminal
Adapter End
Coupling End
Coupling
End
Part No.
Male Terminal
Adapter End
Part No.
Size
Std.
Ctn. Qty.
Travel
Length
(in.)
E945D
E945DX
1
/
2
20
4"
E945E
E945EX
3
/
4
15
4"
E945F
E945FX
1
10
4"
E945G
E945GX
1
1
/
4
5
4"
E945H
E945HX
1
1
/
2
5
4"
E945J
E945JX
2
15
8"
E945K
E945KX
2
1
/
2
10
8"
E945L
E945LX
3
10
8"
E945M
E945MX
3
1
/
2
5
8"
E945N
E945NX
4
5
8"
E945P
E945PX
5
1
8"
E945R
E945RX
6
1
8"
E33447
