5
5) LEFT SCROLL BUTTON –When scrolling through a
screen of data or text, moves to previous character and views
additional information on previous screens, if recorded data
content covers more than one screen.
6) HELP BUTTON – Provides help information.
7) POWER BUTTON
– Long press the button to turn on/off
the tool; short press the button to return to Home screen.
8) DOWN SCROLL BUTTON – Moves down through menu
and submenu items in menu mode. When more than one set of
data are retrieved, use this button to move down to next screens
for additional data. It is also used to view next trouble code
when viewing DTCs.
9) RIGHT SCROLL BUTTON – When scrolling through a
screen of data or text, moves to next character and view
additional information on next screens, if recorded data content
covers more than one screen.
10) TEST BUTTON – Commences a TPMS Test.
11) Y BUTTON – Confirms a selection (or action) from a
menu.
12) USB PORT – Connects the TPMS tool to PC for software
update, data printing or battery charging.
13) POWER PORT – Connects the TPMS tool to the mains with
the charger supplied for battery charging.
14) SD CARD SLOT – Holds SD card.
15) OBD II CONNECTOR – Connects the TPMS tool to the
vehicle’s Data Link Connector (DLC).
3.2 Specifications
1) Display: TFT color display (320 x 240 dpi)
