30
3) Once the sensor IDs are successfully written, a confirm screen
will show up. Press any key to continue the TPMS diagnostic
procedure. (Figure 4.24)
Figure 4.24
NOTE: The sensor writing procedure may vary for different
vehicles being serviced. Please follow the onscreen instruction
and take appropriate measures and selections to complete the
process.
NOTE: If there are untested sensors in the vehicle, the writing
ID process cannot proceed. The tool will display a warning
message as below.(Figure 4.25) In this case, follow the sensor
check procedure to activate all sensors in vehicle and register
sensor IDs again.
Figure 4.25
IMPORTANT: Make sure to turn the ignition off before connecting
/disconnecting the OBDII Cable to/from the TPMS tool; otherwise
it may cause the Malfunction Indicator Light (MIL) to turn on.
