ASD Series : Product Specifications
Physical
30 kW
20 kW
10 kW
Width
19.00in (48.3cm)
19.00in (48.3cm)
19.00in (48.3cm)
Depth
30.00” (76.2 cm)
30.00” (76.2 cm)
30.00” (76.2 cm)
Height
3U - 5.22” rack mount (13.25 cm)
3U - 5.22” rack mount (13.25 cm)
3U - 5.22” rack mount (13.25 cm)
Weight
≤125 lbs (56.69 kg)
Shipping Weight
Contact factory for more product & shipping weights
Mounting provisions
EIA rack-mount with slide provisions. Recommended rack slide: Jonathan slide, P/N 370EZ-28
AC Input Connector
Phoenix Contact terminal block
Protective Ground
1/4-20 stud
Output Connectors
bus bars with 3/8-16 inserted PEM nuts
Water Connections
3/8-18 NPTF hex bulkhead
Ambient Temperature
0 to 50ºC
Humidity
Relative humidity up to 95%, non-condensing
Advanced Digital Features (Requires Optional Digital Control):
Graphical User Interface
Graphical User Interface (Windows based) enables remote control and display of the supply operation including the a
dvanced features listed below:
Oscilloscope Function (125 Hz)
Up to two parameters; Voltage, current, output impedance, output cable impedance, output cable voltage drop, power delivered…
Data logging
Programmable update rate of 1 sec to 1000 sec (default 10 sec) with last 1000 points stored. Stored parameters include, output
voltage/current, programmed set points, input voltage, output impedance, cable impedance, total power deliver, power meter,
internal faults
System fault reporting
Outside of set point, output impedance (detection of cabling, connection or load problems)
10–320 kW
Water cooling specifications
Flow
1.5 gpm nominal, 1.25gpm minimum, 1.75gpm maximum. Internal condensation must be prevented by ensuring that the
temperature of the coolant is sufficiently high compared with the ambient air dew point
Temperature
25
ºC nominal, 20ºC minimum, 30ºC maximum
Maximum pressure
80 PSI
Pressure drop
typical 12 PSI @ 1.5gpm per chassis
Regulatory
Certified to UL/CSA 61010 and IEC/EN 61010-1 by a NRTL, CE Compliant, LVD Categories: Installation Category II: Pollution Degree 2; Class II Equipment: for Indoor Use Only.
Rack mount equipment requires proper enclosure provided in end use. EMC Directive, EN 61326:1998
-
V1
ASD
ACin Option
ACin (1 character) indicates the AC input voltage:
• D, for 380/400Vrms line to line, nominal voltage.
• E, for 480Vrms line to line, nominal voltage.
-
V2 V3
Option
Where V1, V2, V3 (2 characters)
indicate the individual module voltage levels:
• 40, for a 40V, 250A module.
• 60, for a 60V, 167A module.
• 00, for no module (empty slot).
Option (2 characters) indicates the optional interface type:
• 2A, Advanced digital feature package including full isolated analog
interface and Ethernet (Modbus-TCP) or RS485 interface.
• 2B, Advanced digital feature package including full isolated
analog interface and Ethernet (Industrial Protocol (IP)).
• 2G, Advanced digital feature package including full isolated analog
interface (SG-compatible) and Modbus-RTU (serial) inteface
• 1E, Advanced digital feature package including full isolated analog
interface and EtherCAT interface
• 1D, for SG-compatible isolated analog interface. No access to
advanced digital features or GUI. Serial port is available with
maintenance functions only.
Option (2 characters) indicates
other optional features:
• AA, standard unit AC Real-time clock
(must include advanced digital feature package).
3
