XDC 6 kW
6 kW Digital Controlled Programmable DC Power Supply
Models 10-600 20-300 30-200
40-150
60-100
80-75
100-60
150-40
300-20
600-10
Output Ratings
Output Voltage 1 0-10 V 0-20 V 0-30 V
0-40 V
0-60 V
0-80 V
0-100 V
0-150 V
0-300 V
0-600 V
Output Current 2 0-600 A 0-300 A 0-200 A
0-150 A
0-100 A
0-75 A
0-60 A
0-40 A
0-20 A
0-10 A
Output Power 6000 W 6000 W 6000 W
6000 W
6000 W
6000 W
6000 W
6000 W
6000 W
6000 W
Line Regulation 3
Voltage 1 mV 1 mV 2 mV
2 mV
3 mV
3 mV
3 mV
5 mV
7 mV
10 mV
Current 150 mA 50 mA 50 mA
30 mA
20 mA
20 mA
20 mA
10 mA
5 mA
5 mA
Load Regulation 4
Voltage 10 mV 10 mV 10 mV
10 mV
10 mV
10 mV
10 mV
10 mV
15 mV
30 mV
Current 150 mA 50 mA 50 mA
30 mA
30 mA
20 mA
20 mA
10 mA
10 mA
10 mA
Meter Accuracy
Voltage (0.15% of Vmax) 15 mV 30 mV 45 mV
60 mV
90 mV
120 mV
150 mV
225 mV
450 mV
900 mV
Current (0.5% of Imax) 3 A 1.5 A 1 A
750 mA
500 mA
375 mA
300 mA
200 mA
100 mA
50 mA
Output Noise (0-20 MHz)
Voltage (p-p) 85 mV 80 mV 70 mV
70 mV
70 mV
75 mV
75 mV
80 mV
80 mV
95 mV
Output Ripple (rms)
Voltage 10 mV 10 mV 10 mV
10 mV
10 mV
12 mV
15 mV
15 mV
20 mV
20 mV
Current 5 500 mA 100 mA 50 mA
50 mA
30 mA
30 mA
30 mA
30 mA
20 mA
20 mA
Drift (30 minutes) 6
Voltage (0.04% of Vmax) 4 mV 8 mV 12 mV
16 mV
24 mV
32 mV
40 mV
60 mV
120 mV
240 mV
Current (0.6% of Imax) 3600 mA 1800 mA 1200 mA
900 mA
600 mA
450 mA
360 mA
240 mA
120 mA
60 mA
Drift (8 hours) 7
Voltage (0.02% of Vmax) 2 mV 4 mV 6 mV
8 mV
12 mV
16 mV
20 mV
30 mV
60 mV
120 mV
Current (0.04% of Imax) 240 mA 120 mA 80 mA
60 mA
40 mA
30 mA
24 mA
16 mA
8 mA
4 mA
Temperature Coeffi cient 8
Voltage (0.04% of Vmax/°C) 4 mV 8 mV 12 mV
16 mV
24 mV
32 mV
40 mV
60 mV
120 mV
240 mV
Current (0.06% of Imax/°C) 360 mA 180 mA 120 mA
90 mA
60 mA
45 mA
36 mA
24 mA
12 mA
6 mA
OVP Adjustment Range (0 to 103% of Vmax) 0-10.3 V 0-20.6 V 0-30.9 V
0-41.2 V
0-61.8 V
0-82.4 V 0-103 V
0-154.5 V 0-309 V
0-618 V
Effi ciency 9 85% 87% 87%
87%
89%
89%
90%
90%
91%
91%
1. Minimum output voltage is <0.3% of rated voltage at zero output setting.
2. Minimum output current is <0.2% of rated current at zero output setting when measured with rated load resistance.
3. For input voltage variation over the AC input voltage range, with constant rated load.
4. For 0-100% load variation, with constant nominal line voltage.
5. Current mode noise is measured from 10% to 100% of rated output voltage, full current, unit in CC mode.
6. Maximum drift over 30 minutes with constant line, load, and temperature, after power on.
7. Maximum drift over 8 hours with constant line, load, and temperature, after 30 minute warm-up.
8. Change in output per °C change in ambient temperature, with constant line and load.
9. Typical effi ciency at nominal input voltage and full output power.
Electrical Specifi cations
Operational AC Input Voltage 3-phase 190-242 VAC (47-63 Hz) (standard); 3-phase 342-500 VAC, 47-63 Hz, 3 wire and safety ground (optional)
Power Factor (minimum) 0.95 (nominal 208 Vrms); 0.9 (nominal 400 Vrms HV input option)
Remote Analog Programming Voltage and current programming inputs; 0-5 V, 0-10 V (default) voltage sources. Galvanically isolated from supply output.
Remote Analog Monitoring Voltage and current monitor outputs 0-5 V, 0-10 V (default) ranges for 0-100% of output. Galvanically isolated from supply output.
Dimensions (HxWxD) 5.22 x 19.0 x 21.0” (133 x 483 x 533 mm)
Weight Approximately 75 lb (34 kg)
Warranty 5 years
Approvals CE marked units meet: EN61010-1, EN61000-6-2 and EN61000-6-4; CSA C/US certifi ed to UL3111-1 and CSA C22.2 No 1010.1
Meets USA EMC standard: FCC, part 15B, class A; Meets Canadian EMC standard: ICES-001 Class A.
Note: Specifi cations are subject to change without notice.
