O
UTPUT
Voltage: See table
Current: See table
Constant Voltage Mode
Noise and Ripple: See table
Regulation
Line and Load Combined:
0.1% of the
voltage setting or specification in table,
whichever is greater
Transient Response: Typically recovers in
40 ms to within 1% of steady-state output
voltage for a 50% to 100% or 100% to 50%
load change
Stability: 0.1% of maximum voltage over
8 hours after 30 minute warm up time at
fixed line, load and temperature
Temperature Coefficient: 0.02%/°C of
maximum output voltage
Constant Current Mode
Ripple: See table
Regulation
Line and Load Combined:
0.1% I
0
max. of
the output current setting or specification in
table, whichever is greater
Stability: 0.1% of maximum current over 8
hours after 30 minute warm-up time at fixed
line, load and temperature
Temperature Coefficient: 0.04%/°C of
maximum output current
I
NPUT
Voltage and Frequency: 480 VAC ± 10%,
50-60 Hz, three phase
Voltage Options: See Input Voltage Options
Current: See table
G
ENERAL
Operating Temperature: 0° to 50°C
(derated above 30°C)
Storage Temperature: -45°C to 85°C
Cooling: Forced air, fan cooled
Humidity Range: 0-90% RH,
non condensing
Efficiency: 80% at full rated output (typical)
Series Operation: 200 VDC max.; consult
Sorensen for series operation of more than
2 units
Parallel Operation: Master/slave operation
up to 3 units. Consult factory for details.
Overvoltage Protection: Adjustable
5-110% of rated output. Selectable front
panel or remotely programmable
Meter Accuracy: 1% of full scale + 1 count
Voltage Programming: 100 mV per 1% of
rated output (0-10 V for 0-100% of rated
output)
Current Programming: 100 mV per 1% of
rated output. (0-10V for 0-100% of rated
output)
Resistive Programming: 100 Ω per 1% of
rated output (0-10 k Ω for 0-100% of rated
output)
Remote Sense: 5V max. drop in
(+) power lead or (-) power lead
Software: LabVIEW® driver for M9C/M85,
programs can be downloaded at no cost at
www.sorensen.com/support/downloads.cfm
Regulatory Compliance: CE Mark
(<300V models only)
Dimensions: 7U or 12.25” (311 mm) H x
19” (482 mm) W x 24” (609 mm) D
Weight: 310 lbs. (141 kg)
Shipping Weight: 380 lbs. (172 kg)
O
PTIONS
& A
CCESSORIES
M5: SCR crowbar
M9C: Internal IEEE-488/RS 232 Interface
M36: CE Mark (<300V models only)
M85: Multichannel slave interface
M86: Parallel cable
Input Voltage Options
Specifying Note: Select AC input voltage option
below and add as a part number suffix to specify
power supplies (listed as 50-60 Hz, three phase)
T1: 208 VAC T5: 480 VAC
T2: 380 VAC T8: 220 VAC
T3: 415 VAC T10: 230 VAC
T4: 440 VAC T11: 400 VAC
PRO-T Accessories
Caster Cart Kit: Part No. 1064395-1
