HPD Series : Product Specifications
1
Environmental
Operating Temperature 0 to 30°C for full rated output. Above 30°C, derate output linearly to zero at 70°C.
Storage Temperature - 55 to 85°C
Humidity Range 0 to 80% RH, non-condensing
Physical
Dimensions Width: 4.2” (109.2 mm)
Height: 5.2” (134.7 mm)
Depth: 11.7” (297 mm)
Weight Approximately 7.7 lb (3.5 kg)
Input
Operational AC Input Voltage Single unit: 104-127 Vac at 6 Arms; 47-63 Hz
General
Switching Frequency 100 kHz (nominal)
Voltage Mode Transient Response Time < 500 μs recovery to 50 mV band for ±50% load change in the range of 25% to 100% of the rated load
Front Panel Voltage and Current Control 10-turn voltage and 1-turn current potentiometers (10-turn current optional)
Front Panel Voltage Control Resolution 0.02% of maximum voltage
AC Input Connector Type EC 320 connector
Approvals CE-marked units meet: EN61010-1, EN61000-6-2 and EN61000-6-4; CSA C/US certified to UL61010-1B and CSA C22.2 No 1010.1;
Meets USA EMC standard: FCC, part 15B, Class A; Meets Canadian EMC standard: ICES-001, Class A.
Analog Programming (with optional APG interface installed)
Remote On/Off and Interlock 2 to 25 Vdc high. <0.8 Vdc low. User-selectable.
Remote Analog Programming Option 0-10 Vdc for 0-100% of rated voltage or current ±1.0%, 0-10kΩ for 0-100% of rated voltage or current ±1.0%
Remote Monitoring 0-10 Vdc for 0-100% or rated voltage or current ±1.0%
Over Voltage Protection Trip Range 3 V to full output ±10%
Tracking Accuracy ±1% for series operation
300 W
109
