www.ProgrammablePower.com
Output : Voltage and Current
Models 15-20 30-10 60-5
Output Ratings
Output Voltage 0-15 V 0-30 V 0-60 V
Output Current 0-20 A 0-10 A 0-5 A
Output Power 300 W 300 W 300 W
Line Regulation 2
Voltage (0.01% of Vmax + 2 mV) 3.5 mV 5 mV 8 mV
Current (0.05% of Imax + 2 mA) 12 mA 7 mA 4.5 mA
Load Regulation 3
Voltage (0.01% of Vmax + 2 mV) 3.5 mV 5 mV 8 mV
Current (0.05% of Imax + 2 mA) 12 mA 7 mA 4.5 mA
Meter Accuracy
Voltage (1% of Vmax + 1 count) 250 mV 400 mV 700 mV
Current (1% of Imax + 1 count) 300 mA 200 mA 60 mA
Output Noise (90-20 MHz)
Voltage (p-p) (0-20 MHz) rear panel 75 mV 75 mV 100 mV
Voltage (p-p) (0-20 MHz) front panel 100 mV 100 mV 180 mV
Output Ripple
Voltage rms, rear panel 5 mV 5 mV 5 mV
Voltage rms, front panel 10 mV 10 mV 10 mV
Drift (8 hours) 4
Voltage (0.02% of Vmax) 3 mV 6 mV 12 mV
Current (0.08% of Imax) 16 mA 8 mA 4 mA
Temperature Coefficient 5
Voltage (0.015% of Vmax/°C) 2.25 mV 4.5 mV 9 mV
Current (0.02% of Imax/°C) 4 mA 2 mA 1 mA
Specifications subject to change without notice.
1. Specifications indicate typical performance at 25°C ± 5°C, nominal line input of 120 Vac.
2. For input voltage variation over the AC input voltage range, with constant rated load.
3. For 0-100% load variation, with constant nominal line voltage.
4. Maximum drift over 8 hours with constant line, load, and temperature, after 60-minute warm-up.
5. Change in output per °C change in ambient temperature, with constant line and load.
6. Apply accuracy specifications according to the following voltage program accuracy example: Set a model 15-20 power supply to 10 V. The expected result will be within the
range of 10 V ± 60 mV ± 0.1% of the set voltage of 10 V.
HPD Series : Product Specifications
1
HPD 300 W Internal Interface Specifications with RS-232 or GPIB Interface Installed 1,6
Models 15-20 30-10 60-5
Program Accuracy
Voltage (mV) 60 + 0.1% 70 + 0.1% 90 + 0.12%
Current (mA) 75 + 0.12% 50 + 0.12% 25 + 0.1%
OVP (mV) 1500 3000 6000
Readback Accuracy
Voltage (mV) 45 + 0.3% 90 + 0.3% 175 + 0.3%
Current (mA) 75 + 0.12% 40 + 0.12% 25 + 0.1%
