Atec Yokogawa-DL9000 Series - Manual (Page 7)

• Before operating the product, read the user's manual
thoroughly for proper and safe operation.
Note
Microsoft, MS, Windows, and Internet Explorer are registered trademarks or trademarks of
Microsoft Corporation in the US and other countries.
This product's TCP/IP software and documentation on TCP/IP software were
developed/manufactured by Yokogawa based on BSD Networking Software, Release1, under
license from the University of California.
Other company names and product names appearing in this document are the registered
trademarks or trademarks of their respective companies.
[ is a registered trademark of Yokogawa Electric Corporation.]
Related Products
Accessories (Optional)
Name
PB500 (10:1 passive probe)
Mini-clip converter
BNC adapter
Grounding lead
PBA2500 (2.5 GHz active probe)
PBL5000 (5 GHz probe)
DC block
FET probe*
100:1 probe
Differential probe
Differential probe*
PBD2000 (2 GHz differential probe)
Differential probe
Differential probe*
Current probe*
Current probe*
Printer roll paper
Rack mount kit
Model
701943
700971
700972
700973
701913
701974
701975
700939
700978
701921
701922
701923
700924
701920
701933
701932
B9988AE
701984-01
701984-02
Specifications
10 MΩ(10:1), 500 MHz, 1.5 m (one per order)
For use with PB500
For use with PB500
For use with PB500
2.5 GHz BW
5 GHz BW
For 50Ω input, SMA connector
900 MHz BW
100 MHz BW
DC to 100 MHz BW/±700V Max.
DC to 200 MHz BW/±20 V Max.
2 GHz BW
DC to 100 MHz BW/±1400 V Max.
DC to 500 MHz BW/±30 V Max.
DC to 50 MHz BW, 30 Arms
DC to 100 MHz BW, 30 Arms
10 m roll, 10 rolls/order
EIA standard-compliant
JIS standard-compliant
Standard Accessories
Name
Power cable
3 prong-to-2 prong adapter
PB500 passive probe
Printer roll paper (when option /B5 is specified)
User's manual (1 set)
Front panel cover
Rubber leg cap
Soft case
Qty
1
1
4
3
1
1
6
1
DL7400 series
digital oscilloscopes DL1700E series
digital oscilloscopes
1: Please specify this /P2 option if you use either current probes or differential probes such as 701920 or
701922.
2: Choose either one.
3: Choose either one.
4: Choose either one. UART, I
2 C, CAN and SPI bus signal triggers are standard.
Model and Suffix Codes of DL9040/9140/9240
Model
701307
701308
701310
701311
701312
701313
Power cable
Help menu language
Options
Suffix Code
-D
-F
-Q
-R
-H
-HE
-HC
-HK
/B5
/P2 1
/C8 2
/C9 2
/C10 2
/C12 2
/G2 3
/G4 3
/F5 4
/F7 4
/F8 4
Description
DL9040 digital oscilloscope
500 MHz max. 5 GS/s (2.5 GS/s/ch),
2.5 Mword/ch
DL9040L digital oscilloscope
500 MHz max. 5 GS/s (2.5 GS/s/ch),
6.25 Mword/ch
DL9140 digital oscilloscope
1 GHz max. 5 GS/s (2.5 GS/s/ch),
2.5 Mword/ch
DL9140L digital oscilloscope
1 GHz max. 5 GS/s (2.5 GS/s/ch),
6.25 Mword/ch
DL9240 digital oscilloscope
1.5 GHz max. 10 GS/s (5 GS/s/ch),
2.5 Mword/ch
DL9240L digital oscilloscope
1.5 GHz max. 10 GS/s (5 GS/s/ch),
6.25 Mword/ch
UL/CSA standard
VDE standard
BS standard
AS standard
GB standard
English Help
Chinese Help
Korean Help
Built-in printer
Probe power connections on rear panel
(2 outputs for 900 MHz FET probe and current probe)
Built-in HDD + Ethernet Interface
Built-in HDD + LXI Compliant Ethernet Interface
Ethernet Interface
LXI Compliant Ethernet Interface
User-defined math function
Power Supply Analysis Function
UART + I 2 C + SPI bus analyzer
UART + CAN + SPI bus analyzer
UART + I 2 C + CAN + SPI bus analyzer
* requires /P2 option on the DL9000.
year
warranty
• Yokogawa's electrical products are developed and produced in facilities that have received ISO14001 approval.
• In order to protect the global environment, Yokogawa's electrical products are designed in accordance with Yokogawa's Environmentally Friendly Product Design
Guideline and Product Design Assessment Criteria.
Yokogawa's Approach to Preserving the Environment
Subject to change without notice.
[Ed : 03/b] Copyright ©2005
Printed in Japan, 608(KP)
