Digital Storage Oscilloscope
TDS6000B/C Series
Ordering Information
TDS6154C
15 GHz Digital Storage Oscilloscope.
TDS6124C
12 GHz Digital Storage Oscilloscope.
TDS6804B
8 GHz Digital Storage Oscilloscope.
TDS6604B
6 GHz Digital Storage Oscilloscope.
TDS6000B and TDS6000C Models Include:
Accessory pouch, front cover, USB mouse,
USB mini-keyboard, user manual (071-1658-xx),
Documentation CD-ROM (063-3760-xx), product
software CD-ROM (020-2572-xx for TDS6000B
models; 020-2647-xx for TDS6000C models),
operating system restoration CD-ROM (020-2569-xx),
optional applications software CD-ROM (020-2450-xx),
performance verification procedure PDF file, GPIB
programmer’s reference (on product software
CD-ROM), calibration certificate documenting NIST
traceability, 2 540-1 compliance and ISO9000,
power cord, one year warranty. (4) TekConnect
®
to SMA adapters (TCA-SMA), Deskew Fixture
(067-0484-xx).Please specify power plug
when ordering.
Instrument Options
Power Plug Options
Opt. A0 – North America power.
Opt. A1 – Universal EURO power.
Opt. A2 – United Kingdom power.
Opt. A3 – Australia power.
Opt. A5 – Switzerland power.
Opt. A6 – Japan power.
Opt. A10 – China power.
Opt. A99 – No power cord or AC adapter.
Manual Language Options
Opt. L5 – Japanese manual.
Opt. L7 – Simplified Chinese manual.
Opt. L10 – Russian manual.
Disk Drive Options
Opt. FHD – Front-panel 40 GB removable hard
disk drive, replaces front panel CD-R/W which
is moved to the back.
Cables
GPIB Cable (1 m) – Order 012-0991-01.
GPIB Cable (2 m) – Order 012-0991-00.
RS-232 Cable – Order 012-1298-00.
Centronics Cable – Order 012-1214-00.
Mounting Options
1K – K4000 Oscilloscope Cart.
1R – Rackmount Kit.
Service Options
Opt. C3 – Calibration Service 3 Years.
Opt. C5 – Calibration Service 5 Years.
Opt. D1 – Calibration Data Report.
Opt. D3 – Calibration Data Report 3 Years
(requires Option C3).
Opt. D5 – Calibration Data Report 5 Years
(with Option C5).
Opt. R3 – Repair Service 3 Years.
Opt. R5 – Repair Service 5 Years.
Acquisition Memory Options
TDS6000B Models:
2M – 8 M samples on all channels.
3M – 16 M samples on all channels.
4M – 32 M samples on all channels.
TDS6000C Models:
2M – 16 M samples on two channels;
8 M samples on all channels.
3M – 32 M samples on two channels;
16 M samples on all channels.
4M – 64 M samples on two channels;
32 M samples on all channels.
Software Options
CP2 *1 – TDSCPM2 ANSI/ITU Telecom pulse
compliance testing software (requires Option SM).
DVI – TDSDVI DVI compliance test solution.
ET3 – TDSET3 Ethernet compliance test software.
HT3 – HDMI compliance test software.
JA3 – TDSJIT3 v2.0 Advanced jitter analysis software.
JE3 – TDSJIT3 v2.0 Essentials jitter analysis software.
J2 – TDSDDM2 Disk drive analysis software.
PW3 *2 – TDSPWR3 Power measurement and
analysis software.
*1 Requires Option SM.
*2 Option 3M and a TCA-1MEG TekConnect 1 M Ω buffer
amplifier are recommended for use with this software.
RTE – TDSRT-Eye ™ Serial Data Compliance and
Analysis Software.
RJA – Software Bundle of TDSJIT3 v2.0 (Opt. J3A),
TDSRT-Eye (Opt. RTE), and Protocol Trigger Decode
(Opt. PTD).
RSA – Software Bundle of TDSJIT3 v2.0 (Opt.
J3A), RT-Eye (Opt. RTE), Serial Trigger (Opt. ST),
Protocol Trigger and Decode (Opt. PTD), and Serial
Mask testing (Opt. SM).
PCE *3 – PCI Express ™ Compliance Module for
Option RTE.
PTD – Protocol Trigger and Decode (provides
protocol decode on all models, requires Opt. ST for
protocol triggering on the TDS6000C series only).
IBA *3 – InfiniBand Compliance Module for Option RTE.
SM – Serial communications mask testing (enables
hardware clock recovery).
SST – SATA and SAS Analysis Software Module
for Option RTE.
ST – Serial pattern trigger (enables hardware
clock recovery)
USB *4 – TDSUSBS USB2.0 Compliance test S/W only.
Recommended Accessories
P7313 – 12.5 GHz Differential Probe.
P7380 – 8 GHz Differential Probe.
P7380SMA – 8 GHz Differential Probing System.
AFTDS – Telecom differential electrical interface
adapter (for line rates <8 MB/sec; requires TCA-
BNC adapter).
Keyboard (USB interface) Full-size Keyboard
with 4-port USB Hub – Order 119-6297-00.
Transit Case – Order 016-1942-00.
TekConnect Adapters –
TCA-1MEG: TekConnect high-impedance buffer
amplifier. Includes P6139A passive probe.
TCA-SMA: TekConnect-to-SMA Adapter.
TCA-N: TekConnect-to-N Adapter.
TCA-BNC: TekConnect-to-BNC Adapter.
TCA75: 4 GHz precision TekConnect ® 75 Ω to
50 Ω adapter with 75 Ω BNC input connector.
Oscilloscope Cart – Order K4000.
Software – WSTRO: WaveStar ™ waveform capture
and documentation software.
Test Fixtures– TDSUSBF: TDSUSB test fixture for
use with Opt. USB.
*3 Requires Option RTE (Serial Data Compliance and Analysis).
*4 Requires TDSUSBF (USB Test Fixture).
