Seta AvCount2 Particle Counter
Calibration
AvCount2 utilises 16 point calibration and results are easily verified/recalibrated using NIST traceable standard solutions.
Calibration can be checked at user site or at our authorised regional laboratories.
The Complete AvCount Range
SA1000-0 AvCount
The original instrument: this is Ideal for users focusing on Jet Turbine fuel and those wishing to operate/download via a computer
with the log and show software
SA1200-0 AvCount Battery version of SA1000-0
SA1000-2 AvCount2
Suitable for users testing a range of middle distillate fuels or wishing to use multiple test methods. This version of AvCount also
benefits from touch screen operation
SA1250-2 AvCount2 Skydrol Version
Designed for use with Skydrol hydraulic fluid. Due to the highly corrosive nature of this material the AvCount is fitted with Isolast
seals and a protective inner case
Specifications for AvCount2
Particle Size Range: ISO 11171: 4µm(c) to >70µm(c); ISO 4402: 2µm to >100µm; GOST 17216-71: 2µm to >200µm
Measuring Channels: 15
Counts per Measurement (max): 16.000.000
Sample Viscosity (max): 100mm2/s (from sample bottle) 250mm2/s (@10bar)
Sample Temperature Range: 0 to 80°C
Typical Test Time (IP 565): Less than 6 minutes
Size Bands Reported During Test: As specified in Test Method
Size Bands Reported on Recall: All channels
Results:
Particles/ml or Particles/10ml (Test Method dependant) Cumulative and Distributive Cleanliness Codes, Cumulative or Distributive
(Test Method dependant)
Cell Volume @ Flow Rate: 10ml @ 30ml/min
Total Sample Volume used (typ): 80ml (includes rinse cycles) for IP 565 & ASTM Multi fuel. 20ml other methods
Rugged field case
Integral pump
Touchscreen LCD display
Simple bottle sampling
RS232 and power connections
Simple ‘press to start’ control
In-built printer located in side panel
