Specifications
T
her
m
o
Sc
ient
if
ic
EC
AT
Li
ght
ni
n
g
T
es
t
Sy
s
tem
(
LT
S)
Model F- LTS
LTS Frame/Controller for the operation of individual modules
General Specifications
System Voltage
190-230 VAC, 50/60 Hz, 3Ø Wye 30 Amax
(Optional 190-230 VAC, 50/60 Hz, 1Ø 50 Amax)
Test Types Single Stroke
Multiple Stroke: 1-24 pulses; 10 – 200 ms fixed,
random or irregular 1
st pulse and subsequent
pulse spacings
Multiple Burst: 1-500 pulses; 50 – 1000 us fixed,
random or irregular pulse spacing; 1-24 bursts; 30
– 300 ms fixed, random or irregular burst spacing
Pin Injection
Number of Tests 1 to 999
Test Repetition Rate 3 s to 255 s (at maximum level, min rep
rate may be >3 s)
Control Interface
Display
8x40 character LCD
Remote USB, RS232, Fiber-optic
Safety Features
Emergency Off switch
External Interlock for users (mats, curtains, etc)
Lockout/Tagout capability
Module Bays
3 Full-width / 4 Half-width plug-in module
capability
Environmental Operating Conditions
Temperature
+15°C to +35°C
Humidity 10-75%, non-condensing
Physical Specifications
Height
160 cm (63 in)
Width 107 cm (42 in)
Depth 69 cm (27 in)
Weight 360 kg (800 lb) fully configured
Options Available
LTS-CASTERS
Add-on base for LTS with large 5” casters to
facilitate high threshold and/or aggressive ramp
installations. Increases LTS caster ground
clearance from 1.5” to >5”.
LTS-1PHASE Adds power converter to accept 190-230 VAC,
50/60 Hz, 1Ø 50 Amax to power the LTS
CE Marking
Safety and EMC Directives
Model D561-Lx
LTS Module for WF1, 4, 5A (x indicates level 3, 4 or 5)
For Cable Induction use Model DCI-1 Cable Induction Coupler
General Specifications
WF1 (CI,GI)
Single Stroke , 6.4/69 µs, 50-3800 A, 2000 Voc
Multiple Strokes, 6.4/69 µs, 25-1200 A
WF4 (GI) Single Stroke , 6.4/69 µs, 25-2000V, 2100 Asc
Multiple Strokes, 6.4/69 µs, 10-600 V
WF4 Pin Injection 6.4/69 µs, 50-2000 Voc/10-400 Asc = 5 Ohm
WF5A (CI,GI)
Single Stroke , 40/120 µs, 50-10000 A, 1300 Voc
Multiple Strokes, 40/120 µs, 30-1500 A
WF5A Pin Injection 40/120 µs, 50-1800 Voc/50-1800 Asc = 1 Ohm
Safety Features
Door Interlocks
Safety Sockets
Outputs only connected during Transient
Active Module indicator LED
Voltage Present indicator LED
Environmental Operating Conditions
Temperature
+15°C to +35°C
Humidity 10-75%, non-condensing
Physical Specifications
Full-width ECAT plug-in module
CE Marking
Safety and EMC Directives
Model D567-Lx
LTS Module for WF5A (x indicates level 3, 4 or 5)
For Cable Induction use Model DCI-1 Cable Induction Coupler
General Specifications
WF5A (CI,GI)
Single Stroke , 40/120 µs, 50-10000 A, 1300 Voc
Multiple Strokes, 40/120 µs, 30-1500 A
WF5A Pin Injection 40/120 µs, 50-1800 Voc/50-1800 Asc = 1 Ohm
Safety Features
Door Interlocks
Safety Sockets
Outputs only connected during Transient
Active Module indicator LED
Voltage Present indicator LED
Environmental Operating Conditions
Operating temperature
+15°C to +35°C
Humidity 10-75%, non-condensing
Physical Specifications
Full-width ECAT plug-in module
CE Marking
Safety and EMC Directives
Model D566-Lx
LTS Module for WF1, 4 (x indicates level 3, 4 or 5)
For Cable Induction use Model DCI-1 Cable Induction Coupler
General Specifications
WF1 (CI,GI)
Single Stroke , 6.4/69 µs, 50-3800 A, 2000 Voc
Multiple Strokes, 6.4/69 µs, 25-1200 A
WF4 (GI) Single Stroke , 6.4/69 µs, 25-2000V, 2100 Asc
Multiple Strokes, 6.4/69 µs, 10-600 V
WF4 Pin Injection 6.4/69 µs, 50-2000 Voc/10-400 Asc = 5 Ohm
Safety Features
Door Interlocks
Safety Sockets
Outputs only connected during Transient
Active Module indicator LED
Voltage Present indicator LED
Environmental Operating Conditions
Temperature
+15°C to +35°C
Humidity 10-75%, non-condensing
Physical Specifications
Full-width ECAT plug-in module
CE Marking
Safety and EMC Directives
