Digital Phosphor Oscilloscopes

www.tektronix.com/csa7000

10

Communication Signal Analyzers

CSA7000 Series

P h y s i c a l
C h a r a c t e r i s t i c s
BENCHTOP CONFIGURATION
Dimensions

mm

in.

Height

277

10.9

Width

455

17.9

Depth

425

16.75

Weight

kg

lb.

Net

18

39.6

Shipping

37

81.4

RACKMOUNT CONFIGURATION
Dimensions

mm

in.

Height

277

10.9

Width

502

19.75

Depth

486

19.125

Weight

kg

lb.

Net

19

41.8

Shipping

5.6

12.32

MECHANICAL
Required Clearance

mm

in.

Top

0 or >76

0 or >3

Bottom

0

0

Left side

76

3

Right side

76

3

Front

0

0

Rear

0

0

Environmental

Temperature –
Operating: 0 ºC to +50 ºC, excluding floppy disk
and CD-ROM drives.
+10 ºC to +45 ºC, including floppy disk and
CD-ROM drives.
Nonoperating: –22 ºC to +60 ºC.

Humidity –
Operating: 20% to 80% relative humidity with a
maximum wet bulb temperature of +29 ºC at or
below +50 ºC, noncondensing. Upper limit derated
to 25% relative humidity at +50 ºC.
Nonoperating: With no diskette in floppy disk drive,
5% to 90% relative humidity with a maximum wet
bulb temperature of +29 ºC at or below +60 ºC,
noncondensing. Upper limit derated to 20% relative
humidity at +60 ºC.

Altitude –
Operating: 10,000 ft. (3,048 m).
Nonoperating: 40,000 ft. (12,190 m).

Random Vibration –
Operating: 0.00015 g

2

/Hz from 5 to 350 Hz,

–3 dB/octave from 350 to 500 Hz,
0.000105 g

2

/Hz at 500 Hz.

Overall level of 0.27 g

RMS

.

Nonoperating: 0.0175 g

2

/Hz from 5 to 100 Hz,

–3 dB/octave from 100 to 200 Hz,
0.0875 g

2

/Hz from 200 to 350 Hz,

–3 dB/octave from 350 to 500 Hz,
0.006132 g

2

/Hz at 500 Hz.

Overall level of 2.28 g

RMS

.

Electromagnetic Compatibility – EN 61326
(EU EMC Directive 89/336EEC).

AS/NZS 2064 (Australian EMC Framework).

Safety – UL 3111-1, CSA-22.2 No. 1010.1,
EN61010-1.

Ordering Information

CSA7404

4 GHz Communications Signal Analyzer.

CSA7154

1.5 GHz Communications Signal Analyzer.

All Models Include: Accessory pouch, front cover,
mouse, probe calibration and deskew fixture
(067-0405-xx), O/E Electrical Output to Ch. 1
Input Adapter (013-0327-xx), Fiber cleaning kit
(020-2357-xx), Quick Reference (020-2404-xx),
User Manual (071-7010-xx), GPIB Programmer’s
Reference, TDS/CSA7000 Series Product Software
CD-ROM, TDS/CSA7000 Series operating system
restoration CD-ROM, Optional Applications
Software CD-ROM, Oscilloscope Analysis and
Connectivity Made Easy Kit, Option SM and ST
User Manual (071-1035-xx), Performance verifica-
tion procedure PDF file, NIST, MIL-STD-45662A,
ISO9000 Calibration Certificate and Power Cord.

CSA7404 also includes: (4) TekConnect

TM

to SMA

adapters (TCA-SMA).

CSA7154 also includes: (4) TekConnect to BNC
adapters (TCA-BNC).

Please specify power plug when ordering.

Recommended
Accessories

Probes and Converters

P7260 – 6 GHz Low Capacitance Active Voltage
Probe (TekConnect).

P7350 – 5 GHz Differential Probe (TekConnect).

P6150 – 9 GHz Low Capacitance Passive Voltage
Probe (requires TCA-SMA adapter).

P6158 – 3 GHz Low Capacitance Passive Voltage
Probe (requires TCA-BNC adapter).

CT6 – 2 GHz AC Current Probe
(requires TCA-BNC adapter).

CT1 – 1 GHz AC Current Probe
(requires TCA-BNC adapter).

P6701B – Optical-to-Electrical Converter; 500 nm
to 950 nm (requires TCA-BNC adapter).

P6703B – Optical-to-Electrical Converter;
1100 nm to 1650 nm (requires TCA-BNC adapter).

TCP202 – DC to 50 MHz Current Probe
(requires TCA-BNC adapter).

Test Fixtures

TDSUSBF– USB test fixture to be used
in conjunction with Opt. USB.

Software

VocalLink

TM

Pro – VCLNKP VocalLink Pro Voice

Controlled Software.

VocalLink

TM

Basic – VCLNKB VocalLink Basic

Voice Controlled Software.

WSTRO– Wavestar

TM

waveform capture and

documentation software.

Miscellaneous

Keyboard – Fits in pouch, PS-2 interface;
Order 118-9402-00.

Keyboard – Full-size, USB interface;
Order 119-6633-00.

Service Manual – Order 071-7011-00.

Transit Case – Order 016-1522-00.

GPIB Cable (1M) – Order 012-0991-01.

GPIB Cable (2M) – Order 012-0991-00.

Centronics Cable – Order 012-1214-00.

Optical Connector Adapters

FC/PC – Order 119-5115-00.

SC/PC – Order 119-5116-00.

ST/PC – Order 119-4513-00.

DIN/PC 47256 – Order 119-4546-00.

Diamond 2.5 – Order 119-4556-00.

Diamond 3.5 – Order 119-4558-00.

SMA 2.5 – Order 119-4517-00.

SMA – Order 119-4557-00.

Adapters

TCA75 – 4 GHz precision TekConnect 75

to

50

adapter with 75

BNC input connector.

TCA-SMA – TekConnect-to-SMA Adapter.

TCA-BNC – TekConnect-to-BNC Adapter.

TCA-N – TekConnect-to-N Adapter.

TCA-1 Meg – 1 Meg amplifier, high impedance
buffer 1 M

/10 pF, TekProbe BNC-to-TekConnect;

includes P6139A.

AFTDS – Telecom differential electrical interface
adapter (for line rates <8 Mbps; requires
TCA-BNC adapter).

AMT75 – 1 GHz precision 75

adapter (for line

rates >8 Mbps; requires TCA-BNC adapter).
