Specifications
1–8 WVR500 Waveform/Vector Monitor Service Manual
Table 1–6: Power source
Category Description
Mains Voltage Range Req: 90–250 V.
Mains Frequency Range Req: 48 Hz to 66 Hz.
Power Consumption RI: 25 Watts maximum.
Power Fuse Rating Req : 250 V, 2 A, F-type.
Table 1–7: Physical characteristics
Category Description
Dimensions RI: Height: 1 3/4 inches (44.5 mm).
Width: 8 inches (203.2 mm).
Length: 18 1/2 inches (469.9 mm).
Weight RI: Approximately 4.0 lbs (approximately 1.8 kg).
Table 1–8: Environmental characteristics
Category Description
Temperature RI: Non-Operating: –55
°
C to +75
°
C.
Operating: 0
°
C to +50
°
C.
(IEC 1010-1 compliance to +40
°
C.)
Altitude RI: Non-Operating: To 50,000 feet.
Operating: To 15,000 feet.
(IEC 1010-1 compliance to 2000 meters.)
Equipment Type RI: Measurement (as defined in IEC 1010-1, Annex H).
Equipment Class RI: Class I (as defined in IEC 1010-1 Annex H).
Installation Category RI: Installation Category II (as defined in IEC 1010-1, Annex J). Note: Rated for
indoor use only.
Pollution Degree RI: Pollution Degree 2 (as defined in IEC 1010-1).
Vibration — Operating RI: 15 minutes each axis at 0.015 inch, frequency varied from 10–55–10 Hz in
1-minute cycles with instrument secured to vibration platform. 10 minutes
each axis at any resonant point or at 55 Hz if a resonant point is not found.
MIL-T-28800D, Paragraph 1.2.2, Class 3.
Shock — Non-Operating RI: 30 g, 1/2 sine, 11 ms duration, 3 shocks per surface (18 total).
Transportation RI: Qualified under NSTA Test Procedure 1A, Category II (24 inch drop).
Humidity RI: Will operate at 95% relative humidity for up to five days.
