Specifications
1–4 WVR500 Waveform/Vector Monitor Service Manual
Table 1–1: Vertical deflection system (cont.)
Category Description
Frequency Response Req: 1 V Full Scale: 50 kHz to 6 MHz within 2% of response at 50 kHz.
RI: Specifications apply for full screen height video input signal, with Variable
Gain off, and Flat filter selected.
Req: X5 Gain: 50 kHz to 6 MHz within 5% of response at 50 kHz.
RI: Flat filter selected.
Req: Luminance Filter:
≥
30 dB attenuation at 4.00 MHz.
RI: Response at 15 kHz does not vary between Flat and Luminance filters by
more than 1%.
Transient Response RI: Specifications apply for full screen height video input signal, with Variable
Gain off, 1 V Full Scale or X5 Gain, using the 2T pulse and 2T bar.
Req: Pulse-to-Bar Ratio: X1: 0.99:1 to 1.01:1.
X5: 0.98:1 to 1.02:1.
Req: Field Rate Square Wave or Vertical Window Tilt:
≤
1%.
Req: 25 ms Bar Tilt: ≤
1%.
Req: Overscan:
≤
2% variation in baseline of 100 IRE (700 mV PAL) 12.5T (20T PAL)
modulated pulse as it is positioned over the middle 80% of the screen.
RI: Preshoot:
≤
1%.
RI: Overshoot: X1:
≤
2%.
X5:
≤
4%.
RI: Ringing: X1:
≤
2%.
X5:
≤
4%.
Maximum Absolute Input Level Req:
±
5 VDC + peak AC.
RI: Displays in excess of 200 IRE (1.428 V PAL) may cause frequency response
aberrations.
RI: Maximum Operating Input Voltage: Peak AC + DC should be within +8.0 V
and –5.6 V for proper operation.
DC Input Impedance Req:
≥
15 k
W.
RI: Unterminated.
Return Loss (75
W)
Req:
≥
40 dB from 50 kHz to 6 MHz.
RI: CH-A and CH-B input channels, loopthrough terminated in 75
W. Input in use
or not in use, instrument power on or off, all deflection factor settings.
Loopthrough Isolation RI:
≥
70 dB of isolation between loopthroughs. Measured at F
SC
between CH-A,
CH-B, and EXT REF inputs.
