TV Test Transmitter R&S
®
SFQ
5
Options for transmission simulation
Options
Description/Application
(always state the R&S SFQ serial number when ordering an R&S SFQ option)
Required slots
R&S SFQ-B11
model .02
Fading Simulator,
paths 1 to 6
Fading simulation for up to 6 paths
2 slots for R&S SFQ model .10* delivered before September 1999; serial
number of R&S SFQ must be stated
1
R&S SFQ-B11
model .04
Fading Simulator,
paths 7 to 12
Fading simulation for up to 12 paths;
only in conjunction with option R&S SFQ-B11, model .02
1
R&S SFQ-B5
Noise Generator
BER vs C/N, measurement of system margins;
not in conjunction with option R&S SFQ-B2
1
R&S SFQ-B17
BER Measurement
Only in conjunction with R&S SFQ model .20* or with option R&S SFQ-
B10 or with option R&S SFQ-B6 model >03
0
BB-FM options
Options
Description/Application
(always state the R&S SFQ serial number when ordering an R&S SFQ option)
Required slots
R&S SFQ-B2
Broadband FM Modulator
Satellite FM with 2 FM sound subcarriers,
noise generator included, not in conjunction with option R&S SFQ-B5
Restriction in conjunction with option R&S SFQ-B14:
only one video input on front panel available
3
R&S SFQ-B3
2 FM Sound Subcarriers
2 additional FM sound subcarriers,
only in conjunction with option R&S SFQ-B2
Restriction in conjunction with option R&S SFQ-B10: sound inputs only
for one R&S SFQ-B3 option or one R&S SFQ-B4 option
1
R&S SFQ-B4
2 ADR Sound Subcarriers
2 additional ADR sound subcarriers,
only in conjunction with option R&S SFQ-B2
Restriction in conjunction with option R&S SFQ-B10: sound inputs only
for one R&S SFQ-B3 option or one R&S SFQ-B4 option
1
* Previous model designations.
DVB/8VSB/ISDB-T/J.83-B options
(contd.)
Options
Description/Application
(always state the R&S SFQ serial number when ordering an R&S SFQ option)
Required slots
R&S SFQ-B15
DVB-C/DVB-S Coder
No longer available
R&S SFQ-B21
DVB-C Coder (HW + FW)
Not in conjunction with R&S SFQ-B15, R&S SFQ-B23
1
R&S SFQ-B22
DVB-C (only FW)
Only in conjunction with R&S SFQ-B23, included in R&S SFQ-B21
0
R&S SFQ-B23
DVB-S/-DSNG Coder
(HW + FW)
Not in conjunction with R&S SFQ-B15, R&S SFQ-B21 and R&S SFQ-B6
model .02
1
R&S SFQ-B24
DVB-S/-DSNG (only FW)
Only in conjunction with R&S SFQ-B21, not in conjunction with
R&S SFQ-B6 model .02, included in R&S SFQ-B23
0
R&S SFQ-B25
Satellite Turbo
Only in conjunction with R&S SFQ-B23 or R&S SFQ-B24
0
R&S SFQ-B26
ISDB-T Coder
––
1
R&S SFQ-B14
I/Q Output/Input
Output/input for external applications (e.g. external modulator) and for sig-
nal modification/manipulation (see option R&S SFQ-B2)
0
