115ASX-115ASXT
Power Factor Rating Curves
Input Power Requirements (47-63 Hz)
Output Ratings
115ASX 115ASX
Rated Power (VA)
1 Coupling Mode Form
Output Voltage
2
V
rms
Max
(L-N/L-L)
Current
3
(A
rms
)
Frequency
Range
Input
Power
Unit Height
In/mm/U
Unit Weight
(Lbs/Kg)
1500 Direct 1Ш 132 16 15-1200 1Ш 5.25/133/3U
70/32
NOTES:
1. Rated output power is based on a combination of nominal output voltage, rated current and load power factor. Values stated represent the maximum capabilities of a given model. Consult factory for assistance in determining specifi c
unit capabilities as they might apply to your application.
2. Vmax is output voltage with nominal input and full rated load applied.
3. Available current will vary with output voltage and power factor.
ASX Power Source Specifi cations (PF = 1.0, V
out
> 25% F.S.)
Rated Continuous load current as a function of Power Factor and Output Voltage-Nominal Input Line
* Power Source equipped with soft start feature. In-rush current at application of input power will not exceed recommended input service.
Full Power
15-1,200Hz Direct Coupled
45-1,200 Hz Transformer
Coupled
Output
Frequency
Line Regulation
0.1% max for a
±10% line
change
Load Regulation
(Direct coupled)
0.25% 15 to 400 Hz.,
0.50% 400 to 1,200 Hz.
2 to 5% depending on ratio
Improves to <0.1% with external sense and CSC
enabled .
Output Distortion
0.25% THD
AVG
15 to 200 Hz
1.25% THD
AVG
200 to 1,200 Hz
Ripple and Noise
-66dB
Response Time
60 msec typ.
10-90% load step
Input Voltage
Input Current
Recommended
Unit Service
100VAC
±10%
110VAC
±10%
120VAC
±10%
200VAC
±10%
208VAC
±10%
220VAC
±10%
230VAC
±10%
22
rms
20
rms
18
rms
11
ms
10
rms
10
ms
9
rms
25A 25A 25A 15A 15A 15A 15A
115 ASXT 115 ASXT
Rated Power (VA)
1 Coupling Mode Form
Output Voltage
2
V
rms
Max
(L-N/L-L)
Current
3
(A
rms
)
Frequency
Range
Input
Power
Unit Height
In/mm/U
Unit Weight
(Lbs/Kg)
1500 Direct 1Ш 132 16 15-1200 1Ш 5.25/133/3U
95/43
Transformer 1.5:1
Transformer 2.0:1
Transformer 2.5:1
1Ш
1Ш
1Ш
198
264
330
10.7
8
6.4
45-1200
45-1200
45-1200
240VAC
±10%
9
rms
15A
Short term overloads to 20A are permitted. Operating
time before thermal shutdown or circuit breaker trip
varies from seconds to several minutes depending upon
line and temperature conditions.
OUTPUT VOLTAGE-AC VOLTS RMS
Single Phase Mode
