NOTES:
1. Speed = Normal (1 PLC). For 0.1 PLC, add 0.005% of range to offset specifications, except 200mV, 1A, 10A ranges, add 0.05%. For
0.01 PLC, add 0.05% of range to offset specifications, except 200mV, 1A, 10A ranges, add 0.5%.
2. Accuracies apply to 2- or 4-wire mode when properly zeroed.
3. Manual ohms only – except 2420, 2425, 2430, 2440 for 2
Ω range and 2410 or 2400 for 200MΩ range.
4. Source readback enabled, offset compensation ON. Also available on 2410, 2420, 2425, 2430, and 2440 with similar accuracy
enhancement.
5. In pulse mode, limited to 0.1 PLC measurement.
6. Except 2440; default test current is 5µA.
7. Except 2440; default test current is 0.5µA.
TEMPERATURE COEFFICIENT (0°–18°C & 28°–50°C): ±(0.15 × accuracy
specification)/°C.
SOURCE I MODE, MANUAL OHMS: Total uncertainty = I source accuracy + V meas-
ure accuracy (4-wire remote sense).
SOURCE V MODE, MANUAL OHMS: Total uncertainty = V source accuracy + I meas-
ure accuracy (4-wire remote sense).
6-WIRE OHMS MODE: Available using active ohms guard and guard sense. Max.
Guard Output Current: 50mA (except 1A range). Accuracy is load dependent.
Refer to White Paper no. 2033 for calculation formula.
GUARD OUTPUT IMPEDANCE: <0.1 Ω in ohms mode.
Resistance Measurement Accuracy (Local or Remote Sense) 1, 2, 5
Range
Default
Resolution
Default Test
Current
2400, 2410
Default Test
Current
2420, 2425,
2430, 2440
Normal Accuracy (23°C ±5°C)
1 Year, ±(% rdg. + ohms)
Enhanced Accuracy
(23°C ±5°C) 4
1 Year, ±(% rdg. + ohms)
2400 2410 2420, 2425, 2430, 2440 2400
<0.20000 Ω 3 – – – Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
2.00000 Ω 3 10 µ Ω – 1 A Source I
ACC
+ Meas V
ACC
Source I
ACC
+ Meas. V
ACC
0.17% + 0.0003 Ω Source I
ACC
+ Meas. V
ACC
20.0000 Ω 100 µ Ω 100 mA 100 mA 0.10% + 0.003 Ω 0.11% + 0.006 Ω 0.10% + 0.003 Ω 0.07% + 0.001 Ω
200.000 Ω 1 m Ω 10 mA 10 mA 0.08% + 0.03 Ω 0.09% + 0.1 Ω 0.08% + 0.03 Ω 0.05% + 0.01 Ω
2.00000 k Ω 10 m Ω 1 mA 1 mA 0.07% + 0.3 Ω 0.08% + 0.6 Ω 0.07% + 0.3 Ω 0.05% + 0.1 Ω
20.0000 k Ω 100 m Ω 100 µA 100 µA 0.06% + 3 Ω 0.07% + 6 Ω 0.06% + 3 Ω 0.04% + 1 Ω
200.000 k Ω 1 Ω 10 µA 10 µA 0.07% + 30 Ω 0.07% + 60 Ω 0.07% + 30 Ω 0.05% + 10 Ω
2.00000 M Ω 6 10 Ω 1 µA 1 µA 0.11% + 300 Ω 0.12% + 600 Ω 0.11% + 300 Ω 0.05% + 100 Ω
20.0000 M Ω 7 100 Ω 1 µA 1 µA 0.11% + 1 k Ω 0.12% + 2.4 k Ω 0.11% + 1 k Ω 0.05% + 500 Ω
200.000 M Ω 3 1 k Ω 100 nA – 0.66% + 10 k Ω 0.66% + 24 k Ω Source I
ACC
+ Meas. V
ACC
0.35% + 5 k Ω
>200.000 M Ω 3 – – – Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
Source I
ACC
+ Meas. V
ACC
Series 2400 SourceMeter
®
