Current Accuracy (Local or Remote Sense)
Model Range
Programming
Resolution
Source 1, 3
Accuracy
(1 Year) 3
23°C ±5°C
±(% rdg. + amps)
Default Measurement
Resolution
Measurement 5, 6, 7
Accuracy (1 Year)
23°C ±5°C
±(% rdg. + amps) Source/Sink Limit
2400, 2400-C,
2400-LV
1.00000 µA 50 pA 0.035% + 600 pA 10 pA 0.029% + 300 pA
±1.05A @ ±21 V
±105 mA @ ±210 V 8
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
10.0000 mA 500 nA 0.045% + 2 µA 100 nA 0.035% + 600 nA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 2 50 µA 0.27 % + 900 µA 10 µA 0.22 % + 570 µA
2410, 2410-C
1.00000 µA 50 pA 0.035% + 600 pA 10 pA 0.029% + 300 pA
±1.05A @ ±21 V
±21 mA @ ±1100 V
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
20.0000 mA 500 nA 0.045% + 4 µA 100 nA 0.035% + 1.2 µA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 2 50 µA 0.27 % + 900 µA 10 µA 0.22 % + 570 µA
2420, 2420-C
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
±3.15A @ ±21 V
±1.05 A @ ±63 V
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
10.0000 mA 500 nA 0.045% + 2 µA 100 nA 0.035% + 600 nA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 2 50 µA 0.067% + 900 µA 10 µA 0.066% + 570 µA
3.00000 A 2 50 µA 0.059% + 2.7 mA 10 µA 0.052% + 1.71 mA
2425, 2425-C
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
±3.15A @ ±21 V
±1.05 A @ ±105 V
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
10.0000 mA 500 nA 0.045% + 2 µA 100 nA 0.035% + 600 nA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 2 50 µA 0.067% + 900 µA 10 µA 0.060% + 570 µA
3.00000 A 2 50 µA 0.059% + 2.8 mA 10 µA 0.052% + 1.71 mA
2430, 2430-C
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
±1.05A @ ±105 V
±10.5 A @ ±105 V
(pulse mode only)
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
10.0000 mA 500 nA 0.045% + 2 µA 100 nA 0.035% + 600 nA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 50 µA 0.067% + 900 µA 10 µA 0.060% + 570 µA
3.00000 A 2
10.00000 A 4
500 µA
500 µA 0.059% + 2.8 mA
0.089% + 5.9 mA
10 µA
10 µA 0.052% + 1.71 mA
0.082% + 1.71 mA
2440, 2440-C
10.0000 µA 500 pA 0.033% + 2 nA 100 pA 0.027% + 700 pA
±5.25A @ ±10.5 V
±1.05 A @ ±42 V
100.000 µA 5 nA 0.031% + 20 nA 1 nA 0.025% + 6 nA
1.00000 mA 50 nA 0.034% + 200 nA 10 nA 0.027% + 60 nA
10.0000 mA 500 nA 0.045% + 2 µA 100 nA 0.035% + 600 nA
100.000 mA 5 µA 0.066% + 20 µA 1 µA 0.055% + 6 µA
1.00000 A 50 µA 0.067% + 900 µA 10 µA 0.060% + 570 µA
5.00000 A 50 µA 0.10 % + 5.4 mA 10 µA 0.10 % + 3.42 mA
TEMPERATURE COEFFICIENT (0°–18°C & 28°–50°C): ±(0.15 × accuracy specification)/°C.
CURRENT REGULATION: Line: 0.01% of range. Load: 0.01% of range (except Model 2440
5A range 0.05%) + 100pA.
VOLTAGE LIMIT: Bipolar voltage limit (compliance) set with single value. Min. 0.1% of range.
OVERSHOOT: <0.1% typical (1mA step, RL = 10k
Ω, 20V range for Model 2400, 2410, 2420, 2425,
2430), (10V range for Model 2440).
CONTACT CHECK SPECIFICATIONS (requires -C version)
SPEED: 350µs for verification and notification.
CONTACT CHECK:
2 Ω 15 Ω 50 Ω
No contact check failure <1.00 Ω <13.5 Ω <47.5 Ω
Always contact check failure >3.00 Ω >16.5 Ω >52.5 Ω
NOTES
1. 2400, 2410 Only: Specifications valid for continuous output currents below 105mA. For operation above 105mA
continuous for >1 minute, derate accuracy 10%/35mA above 105mA.
2. Full operation (1A) regardless of load to 30°C (50°C for Model 2420 and 2440). Above 30°C (50°C for Model
2420 and 2440) ambient, derate 35mA/°C and prorate 35mA/ Ω load. 4-wire mode. For current sink operation
on 1A, 3A, or 5A ranges, maximum continuous power is limited to approximately 1/2 rated power or less,
depending on current, up to 30°C ambient. See power equations in the User’s Manual to calculate allowable
duty cycle for specific conditions.
3. For sink mode, 1µA to 100mA range, accuracy is:
Model 2400: ±(0.15% + offset*4). Models 2410, 2420, 2425, 2430, 2440: ±(0.5% + offset*3).
For 1A range, accuracy is:
Model 2400: ±(1.5% + offset*8). Models 2410, 2420, 2425, 2430, 2440: ±(1.5% + offset*3).
4. 10A range only in pulse mode. Limited to 2.5ms pulse width maximum. 10% duty cycle maximum.
5. Speed = Normal (1 PLC). For 0.1 PLC, add 0.005% of range to offset specifications, except 200mV, 1A, 10A
ranges, add 0.05%. For 0.01 PLC, add 0.05% of range to offset specifications, except 200mV, 1A, 10A ranges, add
0.5%.
6. Accuracies apply to 2- or 4-wire mode when properly zeroed.
7. In pulse mode, limited to 0.1 PLC measurement.
8. Model 2400 and 2400-C only.
