MEASUREMENTS
Mode 1: Time interval between excitation
pulse and first back wall echo, using
contact transducers.
Mode 2: Time interval between the first
interface echo after the excitation pulse
and the first backwall echo, using delay
line or immersion transducers.
Mode 3: Time interval between
successive back wall echoes following
the first interface echo after the excitation
pulse, using delay line and immersion
transducers.
Measurement Types: Thickness, Velocity,
or Time of Flight
Thickness Measurement Range*:
0.003 - 25 inches (0.08 - 635 mm)
*Thickness range depends on model, material,
transducer, surface condition, and setup
selected.
Material Velocity Range:
0.02000 - 0.7362 inch/μs
(0.5080 - 18.699 mm/μs)
Resolution (keypad selectable):
LOW: 0.01” (0.1 mm)
STANDARD: 0.001” (0.01 mm)
HIGH: 0.0001” (0.001 mm) (35 & 35DL)
Time of Flight Measurement Range:
0.0 - 109.5 µs
Time of Flight Resolution:
Fixed at 000.01 µs
Measurement Update Rate:
4, 8, 16, or Max Hz (16-20 Hz depending
on application and measurement mode)
Transducer Frequency Range:
2.25 - 30 MHz (35 & 35DL)
0.5 - 5.0 MHz (35HP & 35DL-HP)
Min/Max Mode: Displays current
thickness, minimum or maximum
thickness depending on setting.
Display Hold/Blank: Displays blanks after
last reading or holds reading.
Alarm Mode: Programmable Hi-Low
alarm set points with audible and visual
indicators
Differential Mode: Displays thickness
difference between actual measurement
and reference value.
Reduction Rate Mode: Displays thickness
and percent difference between actual
measurement and reference value.
Application Auto-Recall: Automatically
adjusts internal parameters for various
default and custom transducer setups.
# of Default # of Custom
35 21 10
35DL 21 20
35HP 17 10
35DL-HP 17 20
Other Standard Features: Calibration
Lock Mode, Internal Diagnostic Test
Mode, Metric/English Units, On-board
Statistics (35DL and 35DL-HP only)
POWER SUPPLY
Battery: 3 AA alkaline or NiMH batteries
Operating Time: 150 hours typical battery
life; 30 hours continuous with backlight
on
Low Battery Indicator: Continuously
indicates battery status.
Battery Saver: Auto Power Off/
Continuous On
AC Power Supply: Optional
GENERAL
Environmental IP-65 compliant:
Splash-proof, impact-resistant case.
Sealed, color-coded keypad with tactile
and audible feedback.
Operating Temperature Range:
-10°C to +50°C (+14°F to 122°F)
Size: 3.31” W x 6.0” L x 1.50” H
(84 x 152 x 84 mm)
Weight: 8.5 oz. (0.24 kg)
Custom Language Utility: Allows
translation of display text in many
languages.
35DL & 35DL-HP
INTERNAL DATA LOGGER
Data Logger: The 35DL & 35DL-HP
identify, store, recall, clear, and transmit
thickness readings and transducer setup
information via the USB port or optional
RS-232.
Max. # of Stored Values: Over 8,000 or
350 waveforms with thickness readings
(with Waveform Option)
Stored Data Documentation: Each saved
thickness reading is fully documented
with measurement status flags and a
setup number that identifies parameters
such as velocity, transducer, etc.
File Name Length: 8 alphanumeric
characters
Identification Codes: 10 character
alphanumeric Identification Code system
identifies or locates stored data
4 File Templates: Incremental, Sequential
and 2D Grid. Manual files from PC.
STANDARD INCLUSIONS
Wrist Strap, 3 AA Batteries, Test Block,
Transducer Cable, Couplant, Carrying
Case, Instruction Manual, Two-Year
Limited Warranty
OPTIONAL ACCESSORIES
35/WF Live Waveform
Gageview Interface Program
35DL/RS232 RS-232 output
35DLHP/RS232 RS-232 output
35PCScope PCScope Program
USB/ADP-115 AC-115 Power Supply
USB/ADP-230 AC-230 Power Supply
MG2/RPC Protective Rubber Boot
35/DLRETRO Upgrade 35 to 35DL
35HP/DLRETRO Upgrade 35HP to
35DL-HP
