Version 02.00, March 2013
Rohde & Schwarz R&S ® ESL EMI Test Receiver 9
General data
Remote control
LAN interface
10/100BaseT, RJ-45
IEC/IEEE bus (GPIB) R&S ® FSL-B10 SCPI 1997.0
Display
Resolution
640 × 480 pixels
Pixel failure rate <2 × 10 –5
Mass memory
Mass memory
flash disk (internal), USB memory stick
(not supplied)
Data storage >500 instrument settings and traces
Temperature
Operating temperature range
+0 °C to +50 °C
Permissible temperature range +0 °C to +55 °C
Storage temperature range –40 °C to +70 °C
Climatic loading +25 °C/+40 °C at 85 % relative humidity
(IEC 60068-2-30)
Mechanical resistance
Vibration sinusoidal
IEC 60068-2-6
random IEC 60068-2-64
Shock 40 g shock spectrum,
in line with MIL-STD-810E, method 516.4
procedure 1, IEC 60068-2-27
Power supply
Input voltage range, AC, nominal
100 V to 240 V
AC supply frequency 50 Hz to 400 Hz
Input current, AC 0.9 A to 0.3 A
Input voltage range, DC, nominal R&S ® FSL-B30 10 V to 28 V
Input current, DC R&S ® FSL-B30 8.0 A to 2.2 A
Power consumption typ. 45 W, max. 65 W with all options
Safety IEC 61010-1, EN 61010-1, UL 61010B-1,
CSA C22.2 No. 1010-1
Test mark VDE, GS, CSA, CSA-NRTL
EMC EMC Directive 2004/108/EC including:
EN 61326 class B (emission)
CISPR 11/EN 55011/group 1
class B (emission)
EN 61326 table A.1 (immunity,
industrial)
Dimensions (W × H × D) with handle 408.8 mm × 158.1 mm × 465.3 mm
(16.09 in × 6.22 in × 18.32 in)
without handle 342.3 mm × 158.1 mm × 367.0 mm
(13.48 in × 6.22 in × 14.45 in)
Weight without options <7 kg (<15.43 lb)
with battery pack <8 kg (<17.64 lb)
Recommended calibration interval 1 year
operation with external reference 2 years
