Version 02.00, March 2013
Rohde & Schwarz R&S ® ESL EMI Test Receiver 13
R&S ® FSL-K30 application firmware for noise figure and gain measurements
Frequency
Frequency range R&S ® ESL3 100 kHz to 3 GHz
R&S ® ESL6 100 kHz to 6 GHz
Measurement bandwidth 10 Hz to 10 MHz (–3 dB) in 1/3 sequence
Noise figure and gain measurement
Noise figure
Measurement range
0 dB to 35 dB
Resolution 0.01 dB
Accuracy instrument uncertainty (95 % confidence level)
frequency range 100 kHz to 10 MHz
measurement with external preamplifier
(gain 50 dB, noise figure <5 dB),
RBW <10 kHz, DUT noise figure
1 dB to 10 dB and gain >10 dB 0.3 dB
frequency range >10 MHz to 6 GHz
measurement with external preamplifier
(gain 30 dB, noise figure <5 dB),
RBW 1 MHz, DUT noise figure
1 dB to 10 dB and gain >10 dB 0.3 dB
R&S ® FSL-B22 (internal preamplifier)
active, measurement with external
preamplifier (gain 20 dB, noise figure
<5 dB),
RBW 1 MHz, DUT noise figure
1 dB to 10 dB and gain >10 dB
0.3 dB
Gain
Measurement range
0 dB to 60 dB
Resolution 0.01 dB
Accuracy frequency range 100 kHz to 10 MHz
measurement with external preamplifier
(gain 50 dB, noise figure <5 dB),
RBW <10 kHz 0.2 dB
frequency range >10 MHz to 6 GHz
measurement with external preamplifier
(gain 30 dB, noise figure <5 dB),
RBW 1 MHz 0.2 dB
Required hardware
Spectrum analyzer
Noise source supply
via 28 V connector on rear panel of
R&S
® FSL
R&S ® FSL-B5
Noise source recommendation NoiseCom NC346
Preamplifier, external frequency range 100 kHz to 3/6 GHz gain approx. 30 dB, noise figure max. 5 dB
