Version 02.00, March 2013
Rohde & Schwarz R&S ® ESL EMI Test Receiver 3
Specifications
Specifications apply under the following conditions:15 minutes warm-up time at ambient temperature, specified environmental
conditions met, calibration cycle adhered to. Data without tolerances: typical values only. Data designated 'nominal' applies to design
parameters and is not tested. Rohde & Schwarz equipment is designed for reliable operation up to an altitude of 3000 m above sea
level, and for transport up to an altitude of 4600 m above sea level.
Frequency
Frequency range R&S ® ESL3 9 kHz to 3 GHz
R&S ® ESL6 9 kHz to 6 GHz
Frequency resolution 1 Hz
Reference frequency, internal
Accuracy
(time since last adjustment × aging rate) +
temperature drift + calibration accuracy
Aging per year standard 1 × 10 –6
with R&S ® FSL-B4 OCXO reference
frequency option
1 × 10 –7
Temperature drift (+5 °C to +45 °C) standard 1 × 10 –6
with R&S ® FSL-B4 OCXO reference
frequency option
1 × 10 –7
Max. initial calibration accuracy standard 5 × 10 –7
with R&S ® FSL-B4 OCXO reference
frequency option
5 × 10 –8
Frequency readout
Marker resolution
1 Hz
Uncertainty ±(marker frequency × reference
uncertainty + 10 % × resolution bandwidth
+ ½ (span / (sweep points – 1)) + 1 Hz)
Marker tuning frequency step size default
marker step size = sweep points span / 500
span / (sweep points – 1)
Frequency counter resolution 1 Hz
Count uncertainty S/N > 25 dB ±(frequency × reference uncertainty +
½ (last digit))
Frequency span 0 Hz, 10 Hz to 3/6 GHz
Span uncertainty 3 %
Spectral purity SSB phase noise f = 500 MHz
Carrier offset 1 kHz typ. –95 dBc (1 Hz)
10 kHz <–98 dBc (1 Hz), typ. –103 dBc (1 Hz)
100 kHz <–98 dBc (1 Hz), typ. –105 dBc (1 Hz)
1 MHz <–115 dBc (1 Hz), typ. –120 dBc (1 Hz)
Receiver scan
Scan scan with max. 10 subranges with
different settings
Measurement time per frequency 100 µs to 100 s
Number of measurement points 1000000 per trace
Sweep time
Range span = 0 Hz 1 µs to 5 µs in 125 ns steps
5 µs to 16000 s in 5 % steps
10 Hz ≤ span ≤ 3.2 kHz 2.5 ms to 5 s/Hz × span
3.2 kHz < span ≤ 1.5 GHz 2.5 ms to 16000 s
1.5 GHz < span ≤ 3 GHz 5 ms to 16000 s
span > 3 GHz 10 ms to 16000 s
Uncertainty span = 0 Hz nominal 0.1 %
span ≥ 10 Hz nominal 3 %
