7 6
RAPTOR-MS
(values @240 Vac, 50 Hz, 1 turn sec. 960 mm 2 , measured 25 cm on each side)
HIGH CURRENT OUTPUT
Output Current Output Voltage
No Load V (0%Imax) 0 - 1.20 Vac - Continuous
3.8 KAac (25%Imax) 0 - 0.81 Vac - Continuous
7.5 KAac (50%Imax) 0 - 0.42 Vac - 3 min
9.5 KAac (Imax) 0 - 0.22 Vac - 3 s
No Load Resolution 25 uVac
Output Frequency 20 - 400 Hz (Power reduction applied at 50 > f > 60 Hz)
LOW CURRENT OUTPUT (not simultaneous with high current output)
Output Current 0 - 35 Aac (0 – 9 Aac continuous)
Voltage Output 0 - 200 Vac
Output Frequency 20 - 400 Hz (Power reduction applied at 50 > f > 60 Hz)
Isolated output Yes
Protection fuse
MEASUREMENTS
Secondary Current (for high current output)
Ranges 0-1 KAac/N; 0-15 KAac/N (n: number of secondary turns)
Resolution 1 Aac, 10 Aac
Accuracy ±0.2% of the value ±0.2% of the range
Phase angle ±0.25º
AMMETER/LOW LEvEL vOLTMETER
Ammeter Ranges 0 - 0.2 / 0 - 2 / 0 - 20 Aac
Ammeter Resolution 0.1 mAac, 1 mAac, 10 mAac
Ammeter Impedance <10 mΩ
Voltmeter Ranges 0 - 30 mVac, 0 - 0, 3 Vac, 0 - 3 Vac
Voltmeter Resolution 0.015 mVac, 0.15 mVac, 1.5 mVac
Voltmeter Impedance >3000 KΩ
Frequency range 20 - 400 Hz
Accuracy ±0.1% of the value ±0.1% of the range
Phase angle ±0.25º
Isolated input Yes
vOLTMETER
Ranges 0 - 0.2 / 0 - 2 / 0 - 20 / 0 - 300 Vac
Resolution 0.1 mVac, 1 mVac, 10 mVac, 0.15 Vac
Impedance >120 KΩ
Frequency range 20 - 400 Hz
Accuracy ±0.1% of the value ±0.1% of the range
Phase angle ±0.25º
Isolated input Yes
BINARY INPUT
Type Dry contact / Voltage
Voltage mode Levels 1.5 V, 15 V
Time resolution 1 ms
Max. Voltage 250 Vac
Isolated input Yes
COMMUNICATIONS
2 RS-485 Raptor Bus connectors to control unit Raptor-HH and/or other units
2 IrDA interfaces Two channels for master/slaves linking
GENERAL
Supply 230 V ±10%, 50/60 Hz (single phase)
Weight 35 Kg / 77 lb
Dimensions 550 x 440 x 230 mm / 21 ½” x 17 ½” x 9”
Protections MCB, overload, temperature, supply, communications, polarity
Sec. hole diameter 85 mm
Transport Wheels, folding handle, fixed handle
RAPTOR-SL
(values @240 Vac, 50 Hz, 1 sec.turn 960 mm 2 , measured 25 cm on each side)
HIGH CURRENT OUTPUT
Output Current Output Voltage
No Load V (0%Imax) 0, 0.79 or 1.59 Vac - Continuous
3.8 KAac (25%Imax) 0, 0.67 or 1.34 Vac - Continuous
7.5 KAac (50%Imax) 0, 0.55 or 1.11 Vac - 3 min
15 KAac (100%Imax) 0, 0.30 or 0.61 Vac – 3 s
COMMUNICATIONS
2 IrDA interfaces Two channels for master/slaves linking
GENERAL
Supply 230V ±10%, 50/60 Hz (single phase)
Weight 35 kg / 77 lb
Protections MCB, overload, temperature, supply, communications, polarity
Sec. hole diameter 85 mm / 3 ½”
Transport Wheels, folding handle, fixed handle
RAPTOR-HH
CONTROL
Display Transflective high definition color TFT with resistive Touch Panel
Wheel Rotary Encoder (Wheel and click)
LEDs Alarm, Connectivity, Power
COMMUNICATIONS
RS-485 Raptor BUS Communication with Raptor-MS
USB Connection to PC (RaptorSync)
RJ-45 Ethernet for software updates
Mini-PC powered by Windows CE
GENERAL
Power Supply
Self-powered from Raptor-MS, or with external
power adapter 5 Vdc
Weight 0.4 Kg / 1 lb
Dimensions 110 x 185 x 35 mm / 4” x 7” x 1 ½”
Case
High quality injection-moulded ABS, strong and ergonomic design, edge
surfaces protected with TPE non-slip material. Magnetic base.
Compliance
The instrument is intended for use in high-voltage substations and
industrial environments.
All EuroSMC products have conformity to CE-marking directives, complies
with IEC and international standards, and are designed and manufactured
in accordance with the requirements of the ISO-9001 Quality Standard
Transport Bag Nylon soft bag
Connection cable 5 m cable / 16 ½ ft cable
The Raptor System: Specifications
