Remote Control Option
The 2001RP can be ordered with
option package 1 (-OP1) to add a
combined RS232C and IEEE-488
remote control interface. Front
panel and bus measurements are
included with this option.
Ordering Information
Models:
2001RP 2000 VA rack-mount AC
Source
Options:
-AV
Avionics version. All
specifications equal to
standard 2001RP with
the following exceptions:
• Voltage ranges:
0-115 / 0-230 V
RMS
• Frequency range:
360 - 5000 Hz
• Current:
17.4 / 8.7 A
RMS
58 / 29 A
PK
• THD: 1.0+1.0/KHz %
above 1 KHz
• Weight:
67 lbs. / 30 Kg
-L22 Locking knobs
-LZ Low output impedance
version, All specifications
equal to standard
2001RP with the follow-
ing exceptions:
• Zo < 100 mΩ.
• Voltage ranges:
0-135 / 0-270 V
RMS
• Frequency range:
16 - 500 Hz
• Current:
14.8 / 7.4 A
RMS
49.4 / 24.7 A
PK
-OP1 Option package 1:
• Measurements
• IEEE-488 / RS232C
Interface and GUI soft-
ware
• Remote Inhibit input
• Function Strobe output
-SKT Universal front panel
mounted output socket
-RMS Rack Mount Slides
Supplied with:
• User and Programming Manual
on CD ROM
• Windows™ Graphical User
Interface (with -OP1 option)
• RS232C Serial Cable (with -
OP1 option)
Lower Power Models
For applications requiring less
than 2000 VA of output power, mod-
els 801RP and 1251RP offer lower
power levels at reduced cost.
These models are housed in a 3.5
inch high rackmount enclosure and
require even less rack height than
the 2001RP. Refer to the 801RP/
1251RP data sheet for details.
Three Phase AC Source
For applications requiring three
phase output up to 667 VA per
phase, refer to the Model 2003RP
data sheet
CE Mark
The 2001RP has been fully
tested for compliance with all ap-
plicable CE Mark requirements.
2001RP Dimension drawing
Contact California Instruments:
TEL: 858 677-9040
FAX: 858 677-0940
Email: [email protected]
Web page: http://www.calinst.com
9689 Towne Centre Drive, San Diego, CA 92121-1964 (858) 677-9040 FAX : (858) 677-0940
© Copyright 1999-2001, California Instruments Corp. Specifications subject to change without notice Printed in the USA. 2001RPDS 03/05
